Specialized Analog Connection Block: Schneider Electric 140CFH00800
Premium Analog Interface Solution
- The 140CFH00800 provides advanced wiring for analog signals.
- This Schneider Electric block has four terminals for each point.
- It handles both field power and loop power configurations.
- The block includes shield connections for noise protection.
- You get eight individually fused points for analog safety.
- It works with Modicon Quantum analog input modules.
- The design ensures clean signal transmission.
Technical Specifications
- Brand: Schneider Electric
- Model: 140CFH00800
- Product Type: Analog Terminal Block
- Connection Points: 8 fused positions
- Terminals Per Point: 4 separate terminals
- Fuse Rating: 0.063 amps per point
- Connector Type: 50-pin SUB-D female
- Mounting: Standard DIN rail
- Wire Range: 12-24 AWG
- Voltage Rating: 300V AC/DC
- Temperature: -40°C to +105°C
- Contact Material: Copper alloy
- Screw Type: Captive design
Compatible Modules
- 140AVI03000 analog voltage input
- 140ACI03000 analog current input
- Perfect for signal isolation
- Ideal for precise measurements
- Maintains signal integrity
Installation Features
- Easy DIN rail mounting
- Clear point labeling
- Separate shield terminals
- Dual power configurations
- Individual fuse access
- Secure screw terminals
- Space-saving design
Power Options
- Field power supply interface
- Loop power supply interface
- Plus and minus terminals
- Shield connection points
- Flexible power setups
- Stable power delivery
Packaging Options
- Single unit package available
- 10-unit bulk pack option
- Single package weight: 400g
- Bulk package weight: 4.7kg
- Protective packaging materials
- Worldwide shipping
- Fast delivery service
Expert Questions & Answers
- What are the four terminals used for?
- Plus, minus, shield, and power supply connections.
- What is the fuse rating per point?
- Each point has 0.063 amp fuse protection.
- Which analog modules work with this block?
- 140AVI03000 and 140ACI03000 modules work perfectly.
- What power configurations does it support?
- Both field power and loop power setups.
- Can I buy multiple units together?
- Yes, single units or 10-unit packs available.
