Product Introduction
140EHC10500 Modicon Quantum high-speed counter module delivers fast counting for industrial tasks. Schneider Electric builds this robust unit for automation systems. Five channels track fast pulses up to 100000 Hz. Eight discrete inputs and eight FET outputs handle signals easily. Local, distributed, and remote racks accept this standard format module. Oiltech Controls provides fast delivery via FedEx, UPS, and DHL. Contact us at info@oiltechcontrols.com or message us via WhatsApp at +86 158 8020 0923 for support.
Technical Specifications
| Brand | Schneider Electric |
| Model | 140EHC10500 |
| Series | Modicon Quantum |
| Module Type | High-speed counter module |
| Measurement Range | 2147483647 dec 32 bits |
| Frequency Response | 100000 Hz |
| Sensitivity | 15…30 V single ended mode |
| Linearity | 1/1 counter input duty cycle |
| Resolution | 32 bits maximum data format |
| Temperature Range | 32 to 140 °F operational |
| Environmental Tolerance | 95 percent relative humidity |
| Interference Resistance | 4 kV contact ESD protection |
| Channels | 5 channels with status LEDs |
| Inputs and Outputs | 8 inputs, 8 FET outputs |
Installation Guidelines
- Mount the module in local, distributed, or remote racks securely.
- Connect external power supply between 19.2 and 30 V DC.
- Wire discrete inputs to match the 24 V REF DC standard.
- Check channel status using the 5 built-in LEDs.
Debugging and Maintenance
- Monitor fault types like loss of output field power instantly.
- Rely on internal short-circuit protection for FET outputs.
- Inspect bus current requirement of 250 mA during checks.
- Review power dissipation values exceeding 6 W safely.
Compatibility Information
- Fully compatible with the Modicon Quantum platform.
- Fits standard Modicon Quantum rack slots.
- Integrates with standard PLC programming software tools.
Certification Information
- Certified by UL 508 industrial standards.
- Complies with CSA Class 1 Division 2 locations.
- Carries marine approvals including DNV, ABS, LR, and RINA.
Package List and Warranty
- One Modicon Quantum counter module unit in package.
- Package weight equals 18.3 oz or 520.0 g.
- Backed by a full 12-month warranty from purchase date.
Shipping Methods
- Fast global delivery available via FedEx, UPS, and DHL.
- Secure packaging protects units during transit.
Typical Application Scenarios
- High-speed industrial counting and positioning systems.
- Factory automation and motion control loops.
- Conveyor tracking and rotary encoder interfaces.
Diagnostic Capabilities
- Real-time monitoring of input voltages up to 30 V DC.
- Instant detection of output short-circuits.
- Visual diagnostics via front panel LEDs.
Frequently Asked Questions
- What is the max frequency? The max frequency is 100000 Hz.
- How many channels exist? The unit features 5 channels.
- What output type is used? It uses Field Effect Transistor outputs.
