140NOA62200 Interbus Master Module – Modicon Quantum
140NOA62200 is a Modicon Quantum Interbus master module. It is Generation 4 with PCP V2.0 profile. This module acts as a master on the Interbus network. It uses twisted pair cabling. Maximum cable distance is 20 m (65.6 ft). It draws 800 mA from the bus. Power dissipation is 4 W. Operating temperature ranges from 0 to 60 °C (32 to 140 °F). This module holds UL and CSA certifications.
This module works with Concept and ProWORX 32 software (V2.5 SR2+). It is compatible with CPUs 140CPU53414B, 140CPU43412A, and 140CPU11303. Memory includes 128 kB RAM and 256 kB firmware EPROM. Communication is RS485 isolated at 500 kbit/s (DIN 66020).
Key features: CE marking, standard format, and 12 LED diagnostics. It supports local rack installation only.
Technical Specifications
| Brand | Schneider Electric |
| Model | 140NOA62200 |
| Series | Modicon Quantum |
| Type | Interbus Master Module (Gen 4) |
| Access Method | Master |
| Profile | PCP V2.0 |
| Cable Type | Twisted pair |
| Max Cable Distance | 20 m (65.6 ft) |
| Bus Current | 800 mA |
| Power Dissipation | 4 W |
| Operating Temp | 0…60 °C (32…140 °F) |
| Storage Temp | -40…85 °C (-40…185 °F) |
| Humidity | 95% non-condensing |
| Altitude | ≤ 5000 m (16404 ft) |
| ESD Immunity | 4 kV contact / 8 kV air (IEC 801-2) |
| RF Immunity | 10 V/m 80…1000 MHz (IEC 801-3) |
| Weight | 0.9 kg (2.0 lb) |
| Certifications | UL, CSA, CE |
| Country of Origin | DE |
Installation & Commissioning
- Rack type: Local rack only. Fits standard Quantum slots.
- Cable: Use shielded twisted pair. Max length 20 m.
- Connectors: Two 9-pin SUB-D ports. One for Interbus link.
- LED status: 12 LEDs show RUN, ACTIVE, faults, and bus segments.
- Setup: Auto-configuration with Concept or ProWORX 32.
- Maintenance: No hot-swap. Power off before removal.
Diagnostic Capabilities
- Red LEDs indicate memory, processor, remote bus, and peripheral faults.
- Yellow LED shows shut down bus segments.
- Green IS-B RUN LED confirms normal Interbus operation.
- Faults appear on module status and software diagnostics.
Compatibility
- Compatible with 140CPU53414B, 140CPU43412A, 140CPU11303.
- Supports up to 6 local racks with 140CPU11303.
- Supports up to 2 local racks with 140CPU43412A or 140CPU53414B.
- Software: Concept, ProWORX 32 (V2.5 SR2 or higher).
- Communication: RS485 isolated at 500 kbit/s (DIN 66020).
Typical Applications
- Automotive assembly lines with Interbus device networks.
- Material handling systems in standard environments.
- Process control for chemical or manufacturing plants.
- Legacy system upgrades needing Interbus master function.
Frequently Asked Questions (FAQ)
- Q: Is this module hot-swappable?
A: No. Power off the rack before inserting or removing. - Q: What is the max cable length?
A: 20 m (65.6 ft) between devices. - Q: Which CPUs are compatible?
A: 140CPU53414B, 140CPU43412A, and 140CPU11303. - Q: Does it work in high humidity?
A: Yes, up to 95% non-condensing. - Q: What software is required?
A: Concept or ProWORX 32 V2.5 SR2 or newer.
Package Contents
- 1 x 140NOA62200 Interbus master module
- Cables and connectors not included
- Mounting hardware not included
Warranty & Shipping
- Warranty: 12 months from shipment date.
- Shipping: FedEx, UPS, DHL – worldwide.
- Lead time: Usually 1-2 business days.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipping with full tracking.
- Tested surplus and refurbished options available.
- 12-month warranty on every module.
- Technical verification before shipment.
- Support for obsolete control systems.
Contact us: info@oiltechcontrols.com or +86 158 8020 0923 (WhatsApp).
More details: visit the Modicon Quantum series page.
