Overview
The Schneider Electric 140NOC78100C is an Ethernet network module for the Modicon Quantum platform.
It connects controllers to modern industrial networks with speed and stability.
Main Advantages
- Supports Ethernet/IP and Modbus TCP.
- Handles up to 64 active connections.
- Full duplex data exchange.
- Built for high uptime systems.
Network Performance
- Transmission speed: 10 or 100 Mbit/s.
- Auto-negotiation on Ethernet ports.
- Low latency for control data.
- Stable communication under load.
Redundancy and Reliability
- Hot standby redundancy supported.
- Fast recovery after failure.
- Redundant ring topology available.
- Daisy chain loop supported.
Built-In Services
- Embedded web server for setup.
- SNMP for network monitoring.
- SMTP alerts for system events.
- NTP time synchronization.
Ports and Media
- RJ45 Ethernet ports.
- 10BASE-T and 100BASE-TX support.
- Twisted pair cabling.
- Embedded 4-port switch.
Environmental and Mechanical Data
- Operating temperature: 0 to 60 °C.
- Storage temperature: -40 to 85 °C.
- IP rating: IP20.
- Rack-mountable format.
- Weight: approx. 0.345 kg.
System Compatibility
- Designed for Modicon Quantum racks.
- Compatible with 140CPU6xxxx CPUs.
- Easy integration into existing systems.
Warranty and Delivery
- Standard warranty: 12 months.
- Careful industrial packaging.
- Shipping via FedEx, UPS, or DHL.
Professional FAQ
- When is hot standby needed?
- Use it in systems that require high uptime.
- Is this module suitable for large networks?
- Yes. It supports up to 64 connections.
- How is configuration done?
- Through the embedded web server.
- Does it reduce network wiring?
- Yes. The built-in switch simplifies layout.
- Is this good for upgrades?
- Yes. It fits existing Quantum racks.
