1606-XLE96B-2: Allen-Bradley Essential 2-Phase Power Supply, 12 V / 96 W
The 1606-XLE96B-2 belongs to the Bulletin 1606-XL Essential line from Allen-Bradley. It takes 2-phase AC 380…480 V input and delivers 12 V DC at 96 W. Output is adjustable from 12 to 15 V. Screw terminals and DIN rail mounting keep panel work straightforward. Typical efficiency is 85.4%. Ripple and noise stay at or below 100 mVpp. The unit is still listed in current technical data, so supply is reliable. It suits machines running on 400 V or 480 V two-phase feeds.
Electrical Data at a Glance
- Input: 2-phase AC 380…480 V
- Output: 12 V DC nominal, adjustable 12…15 V
- Current: 8 A nominal, 8…6.4 A range
- Rated power: 96 W
- Efficiency: 85.4% typical
- Power losses: 16.4 W typical
- Ripple and noise: 100 mVpp max
- Power factor: 0.44 typical
- Derating: 2.5 W/°C above +60 °C
Thermal and Physical Profile
- Operating range: -25…+70 °C
- Derating from +60 to +70 °C, 2.5 W per °C
- Storage temperature and humidity: not published in 1606-TD002
- Protection: IP20, open-frame DIN rail body
- Size (H×W×D): 124 × 40 × 117 mm
- Weight: 0.50 kg
- Terminals: screw type
Standards and Support Terms
- Approvals: UL 60950-1, cUL, CE
- Warranty: 12 months
- Dispatch: 24-28 hours after order confirmation
- Couriers: FedEx, UPS, DHL
Equipment Fit and Application
- Machines fed from 400 V or 480 V two-phase circuits
- Control panels with 12 V sensor and relay loads up to 96 W
- Compact DIN rail spaces where 40 mm width matters
- Export equipment built to European or North American mains
- Panels replacing older single-phase supplies with higher input
Oiltech Controls Review
- The 2-phase input is the key point. Confirm your feed before ordering. A single-phase supply will not work here.
- Efficiency is modest at 85.4%. Budget the 16.4 W loss into enclosure cooling.
- Power factor of 0.44 is normal for this class. Do not pair it with strict PFC requirements.
- Derating above +60 °C is steep. Check panel temperature before full-load use.
- Each unit is load-tested and output-checked before dispatch.
Why Buy From Oiltech Controls?
- 15+ years handling industrial automation spare parts
- Worldwide delivery with tracked parcels
- Surplus and refurbished units, tested before sale
- 12-month warranty on every item
- Voltage and load verification before shipment
- Long-term support for obsolete control systems
FAQ
Q: Can the 1606-XLE96B-2 run on single-phase 230 V?
A: No. The input is 2-phase AC 380…480 V. Wiring it to a single-phase feed will not start the unit and may damage it.
Q: What happens above 60 °C?
A: Output derates by 2.5 W per °C. At +70 °C the available power is well below 96 W. Plan airflow or lower the load.
Q: Is 100 mVpp ripple acceptable for my sensors?
A: For most digital sensors and relays, yes. For analog measurement circuits, add local filtering at the load.
Q: How do I set the output for a 15 V load?
A: Use the adjustment range of 12…15 V. Note that current falls to 6.4 A at the top end. Size the load for the lower current.
Q: Why is this unit still available when other XL parts are discontinued?
A: It remains listed in current Bulletin 1606-TD002 technical data. Stock is still moving, so lead times are shorter than for retired models.
