1606-XLS960EE Allen-Bradley Power Supply – 24 V DC, 960 W, Single-Phase, Parallel-Capable
The 1606-XLS960EE is a Bulletin 1606-XL Performance switched-mode power supply. It delivers 24 V DC at 40 A, 960 W total. Input is single-phase 200–240 V AC. Output trims from 24 to 28 V DC. Two signal contacts are built in: DC OK and shut-down. The unit is marked for parallel use. That lets you raise total current or add redundancy. Mounting is DIN rail or wall.
Core Specification Card
- Model: 1606-XLS960EE
- Brand: Allen-Bradley
- Series: Bulletin 1606-XL, 1606-XLS Performance line
- Input: 200–240 V AC, single-phase nominal
- Output: 24 V DC nominal, adjustable 24–28 V DC
- Output current: 40 A max
- Rated power: 960 W
- Signal contacts: DC OK and shut-down
- Parallel use: Supported and marked
- Mounting: DIN rail or wall
- Protection rating: IP20
- Communication: None. Signal contacts only.
Environmental Ratings
- Operating temperature: -25 to +70 °C.
- Storage temperature: -40 to +85 °C, non-operating.
- Relative humidity: 5–95%.
- Approvals: UL 60950-1, cUL, CE mark.
- No fieldbus or comms protocol support.
Data Not Published
- Dimensions are not listed numerically by Rockwell.
- Weight is not listed numerically by Rockwell.
- Request a measured spec sheet from our team.
- Confirm rail space before you plan the panel.
Parallel Operation Notes
- Use the parallel marking on the front label.
- Keep cable lengths equal between units.
- Set output trim to the same value on each unit.
- Wire the shut-down contact for load shedding.
- Use the DC OK contact for panel status logic.
- Plan fuse and breaker ratings for total current.
Which Equipment Fits
- Panels needing 24 V DC at up to 40 A.
- Lines that require redundant supply capacity.
- Machines with 200–240 V AC single-phase mains.
- Control cabinets using DIN rail power layout.
- Systems where status contacts feed a PLC.
Oiltech Controls Insight
- The 1606-XLS960EE fits high-current 24 V panels.
- Parallel mode allows N+1 redundancy planning.
- Two signal contacts simplify panel diagnostics.
- Single-phase input limits use on 480 V sites.
- Missing dimension data needs a direct check.
- Confirm cabinet space before ordering.
Why Buy From Oiltech Controls?
- 15+ years of industrial automation spare part supply.
- Worldwide shipping by FedEx, UPS and DHL.
- Tested surplus and refurbished units available.
- 12-month warranty on all supplies we sell.
- Technical verification before every dispatch.
- Support for obsolete and legacy control systems.
- Orders ship in 24–28 hours when stock is confirmed.
Shipping and Warranty
- Dispatch in 24–28 hours after order confirmation.
- Courier options: FedEx, UPS, DHL.
- 12-month warranty covers functional faults.
- Report transit damage within 7 days.
- Keep original packaging for returns.
Professional FAQ
Q: How do I wire two 1606-XLS960EE units for redundancy?
A: Set equal output trim on both units. Keep cable lengths matched. Use the parallel marking. Add a decoupling diode if your design needs it. Ask us for a wiring review.
Q: What is the shut-down contact used for?
A: It can drop the output on command. Use it for load shedding or emergency stop logic. Confirm polarity in your panel drawing first.
Q: Can this unit run on 120 V AC?
A: No. The input is 200–240 V AC single-phase. Use a 1606-XLS240E for 120 V sites. Check the nameplate before wiring.
Q: Why are dimensions and weight missing?
A: Rockwell does not publish them for this model. We can measure a unit for you. Send us your rail width and we will confirm fit.
Q: How do I load-test a used unit before installation?
A: Check no-load output at 24 V. Apply a 50% load and watch stability. Test both signal contacts. Listen for fan noise. Our team can share test steps.
