Core Networking Performance
- The 170ENT11002 facilitates rapid data transmission at a steady rate of 10 megabits per second.
- This Schneider Electric module utilizes the Ethernet TCP/IP protocol to ensure stable communication across industrial networks.
- Engineers deploy this unit in both star and multi-drop topologies for maximum system design flexibility.
- The device supports peer-to-peer and master/slave access methods to manage complex data traffic efficiently.
- A unique IEEE global address and user-assigned IP parameters allow for precise network identification and setup.
- The 170ENT11002 incorporates a BOOTP server configuration to assign essential IP parameters during startup.
Technical Specifications
- Brand: Schneider Electric
- Model: 170ENT11002
- Product Line: Modicon Momentum
- Port Type: 100BASE-TX (Physical RJ45 connector for 10BASE-T)
- Baud Rate: 10 Mbit/s
- Control Parameter: CRC-32 error detection algorithm
- Protection Class: IP20 (protection against solid objects over 12mm)
- Operating Temperature: 0 to 60°C (in non-condensing environments)
- Storage Temperature: -40 to 85°C
- Operating Altitude: Below 16,404 feet (5,000 meters)
- Device Capacity: 0 to 32 devices per network segment
- Transmission Medium: Shielded twisted pair cabling
- Net Weight: 0.15 lb (0.07 kg)
Installation and Network Extension
- Mount the 170ENT11002 adapter securely onto the Modicon Momentum I/O base for immediate integration.
- Use standard RJ45 connectors to link the communication port to your existing Ethernet infrastructure.
- Limit cable runs to 3,280 feet without a repeater to maintain signal integrity and strength.
- Employ an external repeater to extend the transmission distance beyond the standard 1,000-meter limit.
- The adapter maintains a fail-safe state to protect your industrial process during network interruptions.
- For technical inquiries, contact info@oiltechcontrols.com or WhatsApp +86 158 8020 0923.
Packaging and Logistics
- 170ENT11002 Communication Adapter (Quantity: 1)
- Protective Industrial Packaging for safe transit
- Global shipping availability via FedEx, UPS, and DHL services
- Package Dimensions: 2.28 in x 7.01 in x 10.24 in
- Total Shipping Weight: 7.725 oz (219 g)
Frequently Asked Questions
- How does the fail-safe mode protect my industrial process?
- The adapter enters a secure fail-state during signal loss to prevent unpredictable machinery behavior.
- What is the benefit of the CRC-32 control parameter?
- This mathematical algorithm detects transmission errors to ensure your data arrives without any corruption.
- Can I use this module in high-altitude environments?
- Yes, the hardware maintains full operational capacity at altitudes reaching up to 5,000 meters.
- How do I choose between a star or multi-drop topology?
- Select a star topology for easy troubleshooting or multi-drop to reduce total cabling requirements.
- Does this unit require specific environmental shielding?
- The IP20 rating requires installation within a clean, dry enclosure to protect against moisture.
