1756-OA8E Allen-Bradley | ControlLogix AC Output Module

Allen-Bradley 1756-OA8E – 8-Channel Fused AC Output Module

Key Features

• 8 protected outputs with electronic fusing
• Works with 74-132V AC systems
• Handles 2A per channel (8A total)
• Built-in overload protection
• Compact single-slot design

Technical Specifications

• Output Type: AC fused
• Voltage Range: 74-132V AC (47-63Hz)
• Current per Point: 2A @60°C, 4A @30°C
• Total Current: 8A @30°C, 4A @60°C
• Switching Speed: 9.3ms @60Hz, 11ms @50Hz
• Terminal Blocks: 1756-TBNH or 1756-TBSH
• Inrush Capacity: 20A for 43ms
• Power Use: 5.5W max
• Isolation: 125V continuous

Easy Installation

• Fits any 1756 ControlLogix chassis
• Hot-swappable design
• LED status indicators

Download Complete Manual

Get all details about the 1756-OA8E: Download Now

Frequently Asked Questions

1. What does electronic fusing do?
   Protects each output from overload damage.
2. Can I use this for motor starters?
   Yes, perfect for small motor controls.
3. How many modules per chassis?
   Up to 17 in large ControlLogix chassis.
4. Is special wiring needed?
   Standard 1756 terminal blocks included.
5. What’s the module weight?
   Approx. 0.5kg (1.1lb).
