1756-OF8IHK | Allen-Bradley ControlLogix Analog Output Module

Allen-Bradley 1756-OF8IHK – Advanced HART Analog Output Module

Key Advantages

• 8 isolated HART channels with individual modems
• High precision 15-bit resolution
• Works with 4-20mA & 0-20mA signals
• Built-in protection (±24V DC overvoltage)
• Conformal coating for harsh environments

Technical Specifications

• Output Type: Isolated HART analog
• Channels: 8 differential (36-pin)
• Current Range: 0-20mA / 4-20mA selectable
• Resolution: 15-bit (24mA range)
• Scan Time: 1 second (HART enabled)
• Isolation: 250V AC continuous
• Protection: ±24V DC overvoltage
• Certifications: C-UL-us, CE, RCM, Ex, KC, EAC
• Terminal Blocks: 1756-TBNH or 1756-TBSH

Setup & Installation

• Fits any 1756 ControlLogix chassis
• Works in local or remote configurations
• Requires terminal block (sold separately)

Download Complete Documentation

Get full specs for the 1756-OF8IHK: Download Manual

Expert Answers

1. What’s the benefit of per-channel HART modems?
   Enables simultaneous communication with multiple smart devices.
2. Can I use this in explosive environments?
   Yes, it has Ex certification for hazardous areas.
3. How does conformal coating help?
   Protects against moisture, dust and chemicals.
4. What’s the accuracy rating?
   ±0.1% of full scale at 25°C.
5. Is special software needed?
   Works with standard ControlLogix programming tools.
