Allen-Bradley 1756-OX8I – 8-Channel Universal Relay Output Module
Key Features
- 8 isolated relay outputs (NO + NC contacts)
- Works with 10-265V AC or 5-150V DC
- Handles 2A resistive or 0.5A inductive loads
- Flexible isolated or non-isolated wiring
- Long 300,000 cycle contact life
Technical Specifications
- Output Type: Form C relay contacts
- Voltage Range: 10-265V AC / 5-150V DC
- Current Rating: 2A resistive, 0.5A inductive
- Contact Resistance: 100mΩ max
- Switching Speed: 13ms max
- Terminal Blocks: 1756-TBCH or 1756-TBS6H
- Isolation: 250V continuous
- Contact Life: 300k cycles (resistive)
- Power Use: 3.1W max
Installation Guide
- Fits any 1756 ControlLogix chassis
- Hot-swappable design
- LED status indicators
Download Complete Manual
Get full details about the 1756-OX8I: Download Now
Frequently Asked Questions
- Can I mix AC and DC voltages?
Yes, each channel is independently isolated. - What’s the maximum switching frequency?
1 operation every 3 seconds at full load. - Does this module need external protection?
Built for direct switching – no additional protection needed. - Can I use this for motor control?
Yes, perfect for small motors up to 0.5HP. - What’s the module weight?
Approx. 0.5kg (1.1lb).
Package Includes
- 1x 1756-OX8I relay module
- Installation guide
