1790D-0W6 Relay Module 6-Output DeviceNet Base

Oiltech Controls Review

The Allen-Bradley 1790D-0W6 addresses a critical requirement in decentralized DeviceNet topologies by providing 6 fully isolated Form A relay contacts. This 1790D-0W6 configuration eliminates the constraints of shared commons, as each output point features its own dedicated COM path (1 point/1 COM). This architecture is vital for mixing AC and DC load voltages on a single physical block without introducing cross-phase interference. The engineering choice of a 37-pin D-shell connector minimizes wiring clutter, providing a robust plug-and-play matrix that speeds up cabinet deployment and field swaps.

Technical Specifications Matrix

• Relay Architecture: 6 Form A contact channels configured as single-pole, single-throw (SPST) normally open
• DC Load Range: 5V DC to 28.8V DC delivering a maximum of 2.0 A resistive current capacity
• AC Load Range: 30V AC nominal delivering a maximum of 2.0 A resistive current capacity
• Minimum Conduction Threshold: Highly sensitive dry-contact switching down to 100 µA at 100 mV DC
• Contact Impedance: Initial contact path resistance rated at a maximum of 30 mΩ
• On-State Voltage Drop: Maximum 0.5V drop measured at 2.0 A resistive load under 24V DC
• Switching Lifetime Metrics: 300 Kcycles under full resistive loads; 100 Kcycles under inductive loads
• Off-State Isolation Leakage: Maximum leakage current restricted to 1.5 mA
• Contact Actuation Delays: Off to On propagation takes under 10 ms; On to Off takes under 10 ms
• DeviceNet Bus Burden: Draws a maximum power dissipation of 1.2 W at 28.8V DC over an 11 to 28.8V DC span
• Field Supply Requirements: 24V DC nominal field bus with an operational voltage band of 19.2 to 28.8V DC
• Field Channel Consumption: Active current draw of 10 mA per channel at 28.8V DC
• Galvanic Physical Isolation: Photocoupler isolation circuit tested at 1250V AC RMS from I/O to internal logic
• Visual Diagnostics: 6 green status LEDs mounted on the faceplate for instantaneous loop state verification
• Physical Termination: Industrial grade 37-pin D-shell connector ensuring locking vibration-proof connection points

Target System Integration

• Interlocking Safety Circuits: Safe isolation switching for master control relays and emergency stop loops
• Motor Control Centers: Direct pilot duty excitation for size 1 through size 4 AC contactor coils
• Variable Speed Drives: Delivering dry run/fault reset command signals to independent VFD terminal strips
• Process Heating Control: Driving small resistive heating elements and localized immersion heaters
• Facility Alarm Infrastructure: Activating heavy-duty multi-tone factory sirens and high-draw strobe arrays

Logistics & Fulfillment Operations

• Dispatch Standard: Orders undergo testing and secure packing for shipment within 24 to 28 hours
• Global Courier Network: Express air transit managed exclusively by premium carriers FedEx, UPS, and DHL
• Hardware Guarantee: Full structural and operational protection backed by our 12-month warranty terms
• Direct Procurement Desk: Forward all enterprise RFQs and bulk pricing inquiries to info@oiltechcontrols.com

Expert Engineering & Selection FAQ

• Q: How do I select between the 1790D-0W6 relay block and a standard solid-state sinking module?
• A: Choose the 1790D-0W6 when your system requires true air-gap physical isolation, zero off-state voltage leakage, or the ability to switch low-voltage AC loads on the same block. If your application demands rapid duty-cycling under 10 ms, select a solid-state module instead to avoid mechanical wear.

• Q: What field installation practice prevents premature contact failure on the 1790D-0W6 when switching inductive coils?
• A: You must install external suppression directly across the load. Use an RC snubber network for AC inductive loads and a flyback diode for DC inductive coils to contain the inductive energy spike. For immediate circuit advice, contact us via WhatsApp at +86 158 8020 0923.

• Q: Can this module operate field devices if the DeviceNet network power supply drops offline?
• A: No, the module requires active DeviceNet bus power (11 to 28.8V DC) to energize the internal logic circuit and photocouplers, even if your 24V DC field power remains fully energized.

• Q: Why does the technical data specify a minimum load of 100 µA and 100 mV DC?
• A: This represents the wetting current required to pierce microscopic contamination layers on the silver alloy contacts. Operating below this threshold can result in unreliable contact closure readings in high-impedance instrumentation loops.

• Q: Is it permissible to route a 120V AC signal through these relay channels?
• A: No, the maximum voltage rating for the 1790D-0W6 contacts is strictly capped at 30V AC or 28.8V DC. Exceeding these limits violates safety isolation margins and risks arc-over damage across adjacent pins on the 37-pin D-shell connector.
