Overview
The 1790D-OV16 is a high-density CompactBlock LDX I/O base module designed for DeviceNet networks, providing 16 non-isolated sinking outputs in a space-saving footprint. Engineered for rapid integration via its 37-pin D-shell connector, the 1790D-OV16 handles up to 4.0A per common, ensuring stable switching for high-duty solenoid valves and industrial relays.
Oiltech Controls’s Insight & Application
- Engineering Verdict: The 1790D-OV16 is the “workhorse” for DeviceNet-based localized control. Its sinking logic is ideal for NPN-compatible loads.
- Internal Architecture: Note that Com 0/Com 2 are internally bridged; professional installers must ensure polarity consistency to prevent common-mode noise across the D-shell interface.
- Optimal Device Fit: Specifically tailored for compact control cabinets, robotic end-effectors, and distributed conveyor systems using Allen-Bradley DeviceNet scanners.
- Contact Technical Support: info@oiltechcontrols.com
Core Technical Specifications
- Output Density: 16 Points, Sinking configuration, non-isolated.
- Operating Voltage: 10V DC min to 28.8V DC max (24V DC Nominal).
- Current Capacity: 0.5 A max per output; 4.0 A max per common group.
- Signal Response: Off to On: ≤ 0.5 ms; On to Off: ≤ 1.0 ms.
- Isolation Barrier: Photocoupler isolation rated at 1250V AC RMS between I/O and logic.
- Power Dissipation: 1.2 W max @ 28.8V DC (Base Module).
- Connection Interface: Integrated 37-pin D-shell connector.
Wiring & Polarity Logic
- Field Power (+): Connect Com 0 and Com 2 to 24V DC.
- Field Power (-): Connect Com 1 and Com 3 to GND.
- Common Grouping: 8 points per 2 COM terminals (1790D-OV16 configuration).
- Status Feedback: 16 Green LED indicators for real-time channel diagnostics.
