1790D-T32BV0 24V DC 32-Point Universal Input Base Module
The 1790D-T32BV0 provides high-density digital interfacing for DeviceNet industrial networks. This universal input base handles 32 points, allowing users to configure either sinking or sourcing wiring schemes. Designed for rugged environments, the 1790D-T32BV0 ensures precise signal detection and robust logic isolation for complex automation tasks. Oiltech Controls offers this unit for immediate integration into high-speed manufacturing lines.
Technical Performance Matrix
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Model Identification: 1790D-T32BV0
- Input Density: 32 universal points (sinking/sourcing)
- Nominal Voltage: 24V DC (Range: 9.6V DC min to 28.8V DC max)
- Off-State Voltage: 5.0V DC maximum threshold
- Input Current: 8 mA maximum per channel at peak 28.8V DC
- Input Impedance: 4.8 KΩ nominal for consistent signal integrity
- Common Configuration: 16 points per group across 4 COM terminals
- Isolation: Photocoupler logic isolation rated at 1250V AC RMS
- Network Power: DeviceNet supply range of 11V to 28.8V DC
- Efficiency: Maximum power dissipation of 1.2 W at full voltage
Oiltech Controls’ Insight & Equipment Compatibility
- This module excels in space-constrained cabinets where high-density I/O is critical.
- Compatible with 24V DC proximity sensors, limit switches, and photoelectric cells.
- Integrates perfectly with Allen-Bradley SLC 500 and ControlLogix systems via DeviceNet.
- Ideal for automotive assembly lines, material handling, and food processing machinery.
- The non-isolated DeviceNet power simplifies wiring for localized sensor clusters.
- Consult our specialists at info@oiltechcontrols.com for advanced system architecture advice.
Installation & Logistical Standards
- Wiring Interface: M3.0 terminal block supporting copper-clad aluminum conductors.
- Torque Spec: Maximum 7 lb-in screw tension to prevent contact damage.
- Status Monitoring: 32 dedicated green LEDs provide immediate diagnostic feedback.
- Warranty: Comprehensive 12-month quality guarantee on all hardware.
- Order Processing: Fast dispatch within 24 to 28 hours from our warehouse.
- Courier Partners: Worldwide express delivery via FedEx, UPS, and DHL.
Professional FAQ & Buying Guide
- Can I mix sinking and sourcing sensors on the same 1790D-T32BV0 module?
- Yes, you can mix them by utilizing the 4 separate common (COM) terminal groups.
- What is the primary benefit of the 4.8 KΩ nominal impedance?
- It reduces false triggering from leakage current while maintaining low heat generation.
- How do I handle field power if the DeviceNet power is non-isolated?
- Ensure your field power supply shares a stable ground with the DeviceNet supply.
- Experience Tip: Is this module suitable for high-vibration environments?
- The M3.0 screw terminals are robust, but we recommend checking torque after initial machine vibration tests.
- Selection Advice: When should I choose the 1790D-T32BV0 over isolated versions?
- Select this model when speed and cost-efficiency are prioritized and logic-to-network isolation is not required.
- Message our tech team via WhatsApp (+86 158 8020 0923) for urgent compatibility checks.
