21000-16-05-00-094-03-02 | Bently Nevada – Proximity Probe Housing Assembly

Product Overview

New Bently Nevada Proximity Probe Housing Model 21000-16-05-00-094-03-02 with 12-month warranty. CSA-certified for explosion safety. Works in hazardous areas. Includes probe, fittings, and dome cover. Meets API 670 standards.

Key Features about 21000-16-05-00-094-03-02

• Probe: 8 mm size with connector (Code 16).
• Cable: 0.5 m (20 in) long (Code 05).
• Depth: 9.4 in penetration (Code 094).
• Fittings: 3/4-14 NPT plug, reducer, 3 cable seals (Code 03).
• Mounting: Standard 3/4-14 NPT threads (Code 02).

Technical Details

• Weight: 1.1 kg (2.4 lb).
• Max Length: 13.5 in (34.3 cm) with cable.
• Temp Range: -50°C to +80°C.
• Material: Aluminum body + stainless steel sleeve.

Certifications

• CSA explosion-proof (Class 1 & 2)
• FCC Part 15 compliant
• RoHS EU 2011/65 approved

What’s Included

• Dome cover & O-rings
• Probe sleeve & thread seal
• 3/4-14 NPT plug + reducer
• 3 cable grips (fits 1/8″ to 3/8″ cables)

Document Download Here:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
