21000-16-10-00-037-03-02 | Bently Nevada – Proximity Probe Housing Assembly

Product Overview

Bently Nevada‘s Proximity Probe Housing (Model 21000-16-10-00-037-03-02) is new & factory-sealed with a 12-month warranty. Certified CSA Type 4 and API 670 compliant. Built for explosive environments in industrial settings.

Order Details

• Full Model: 21000-16-10-00-037-03-02
• Probe: 16 – 8 mm 3300 XL with connector
• Cable: 10 – 1.0 m (39 in) shielded
• Adapter: 00 – Not included
• Depth: -037- 3.7 in (9.4 cm) penetration
• Fittings: 03 – Includes 3/4″ NPT plug, reducer, and 3-size cable grips (1/8-3/16″, 1/4-5/16″, 5/16-3/8″)
• Mounting: 02 – 3/4-14 NPT threads

Key Specs

• Weight: 1.1 kg (2.4 lb) without fittings
• Size: 43.18 cm probe / 83.5 cm total length
• Material: Aluminum body + 304 stainless steel sleeve
• Temp Range: -40°C to 120°C (-40°F to 248°F)
• Safety: Explosion-proof (Class I Div 1)

What’s Included

• Screw-on dome cover
• Threaded conduit ports
• Reverse-mount probe + sleeve
• 2 O-rings + thread seal
• 3/4″ NPT plug & reducer

Applications

Ideal for oil/gas, power plants, and chemical facilities. Meets API 670 standards for safe machine monitoring in hazardous zones.

Document Download Here:21000- 24701- and 164818 Proximity Probe Housing Assemblies Datasheet
