3300 NSv Proximity Probes | 330901-22-90-10-02-00 Without Armor

Bently Nevada 330901-22-90-10-02-00 Proximity Probe

Product Overview

This 3300 NSv proximity probe is made in the U.S.A. It features a 2.2-inch unthreaded length and a 9-inch overall case. The total cable length is 1.0 meter with a miniature coaxial ClickLoc connector. It has a 1/4-28 UNF thread and no armor.

Technical Specifications

• Model: 330901-22-90-10-02-00
• Thread Size: 1/4-28 UNF
• Unthreaded Length: 2.2 in
• Overall Case Length: 9 in
• Cable Length: 1.0 meter (39 in)
• Connector Type: Miniature coaxial ClickLoc, standard cable
• Agency Approval: None required
• Case Material: AISI304 stainless steel
• Tip Material: Polyphenylene sulfide (PPS)
• Cable Specs: 75 Ω coaxial, FEP insulated
• Probe DC Resistance: 4.2 ± 0.5 ohms (1 m cable)
• Operating Temperature: -52°C to +177°C (-62°F to +351°F)
• Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Pressure Seal: Viton O-ring
• Weight: Approx. 14 to 150 g (0.5 to 5.3 oz)

Installation Guide

• Max thread engagement: 0.375 in
• Recommended torque: 5.1 N·m (45 in·lb)
• Max torque: 7.3 N·m (65 in·lb)
• Avoid temperatures below -34°C for long times to protect seal

Model Code Structure

• 330901 – 3300 NSv probe series
• 22 – Unthreaded length 2.2 in
• 90 – Case length 9 in
• 10 – Cable length 1.0 m
• 02 – Mini coaxial ClickLoc connector, standard cable
• 00 – No agency approval required

Industrial Benefits

• Fits compact machine designs
• Reliable under strong vibration
• Works in very high and low temperatures
