Bently Nevada 330910-00-05-05-02-00 | 3300 NSv Proximity Probe
Product Overview
The Bently Nevada 330910-00-05-05-02-00 is a 3300 NSv proximity probe. It is made for machines with tight installation space. The probe gives accurate shaft position and vibration signals. Designed to work in hot, cold, and dusty industrial areas.
Key Technical Data
- Thread Size: M10x1 with armor
- Unthreaded Length: 0 mm
- Case Length: 50 mm
- Cable Length: 0.5 meter (20 inches)
- Connector Type: Miniature coaxial ClickLoc, standard cable
- DC Resistance: 4.0 ± 0.5 ohms at 0.5 m
Materials and Build
- Probe Tip: PPS (Polyphenylene sulfide)
- Case Material: AISI 304 stainless steel
- Cable: 75 Ω coaxial, FEP insulated
- Available Cable Lengths: 0.5 m, 1 m, 5 m, 7 m
Temperature Ratings
- T1: -55°C to +232°C
- T2: -55°C to +177°C
- T3: -55°C to +120°C
- T4: -55°C to +80°C
- T5: -55°C to +40°C
Model Tree (Full Suffix Breakdown)
- 330910: NSv probe series
- 00: 0 mm unthreaded length
- 05: 50 mm case length
- 05: 0.5 meter total cable length
- 02: Miniature ClickLoc connector, standard cable
- 00: No approval required
Package Contents
- 1 x Bently Nevada 330910-00-05-05-02-00 Probe
- New in sealed factory packaging
- 12-month warranty (no certificate included)
