3300 NSv Proximity Probes – Without Armor 330908-12-16-05-02-00

Bently Nevada 330908-12-16-05-02-00 NSv Proximity Probe

Quick Summary

This is a 3300 NSv proximity probe made by Bently Nevada. It is used to check shaft position and vibration in small machines. It has a 3/8-24 UNF thread and no armor. The cable is 0.5 meters long with a ClickLoc connector.

Key Specifications

• Model: 330908
• Unthreaded Tip: 1.2 inches
• Case Length: 1.6 inches
• Cable Length: 0.5 meter (20 inches)
• Thread Size: 3/8-24 UNF
• Connector: Miniature coaxial ClickLoc
• Cable Type: Standard, 75 Ω, FEP-insulated

Material

• Case: AISI304 stainless steel
• Tip: PPS (Polyphenylene sulfide)

Electrical

• Resistance (0.5 m): 4.0 ± 0.5 ohms

Torque Details

• Max Torque: 33.9 N·m (300 in·lb)
• Recommended: 11.3 N·m (100 in·lb)

Temperature Limits

• Working: -52°C to +177°C
• Storage: -52°C to +177°C
• Warning: Do not use below -34°C for long periods

Seal and Pressure

• Seal: Viton O-ring at the tip
• Note: Probe is not pressure-tested before shipping

Weight

• Approx: 14 to 150 g (0.5 to 5.3 oz)

Model Breakdown

• 330908: NSv probe with 3/8-24 UNF thread
• 12: 1.2 inch unthreaded tip
• 16: 1.6 inch case length
• 05: 0.5 meter cable
• 02: ClickLoc connector, standard cable
• 00: No agency approvals

Compatibility

• Works with 3300 NSv extension cables
• Works with 3300 NSv Proximitor sensors

What You Get

• 1 x NSv Probe (330908-12-16-05-02-00)
• 0.5 m built-in cable

Shipping and Warranty

• Ships via FedEx, UPS, or DHL
• Delivery time: 2–7 business days
• Warranty: 12 months
