3300 NSv Proximity Probes – Without Armor 330908-12-18-70-02-00

Bently Nevada NSv Proximity Probe: Compact Machine Health Sensor

3/8-inch industrial vibration monitor for tight spaces. Made in USA with precision engineering.

Complete Model Breakdown

• 330908: 3/8-24 UNF thread probe
• 12: 1.2″ unthreaded section
• 18: 1.8″ total case length
• 70: 7.0 meter cable (23 ft)
• 02: ClickLoc connector
• 00: No agency approvals
• Full Model: 330908-12-18-70-02-00

Key Specifications

• Thread Size: 3/8-24 UNF
• Cable Length: 7.0 meters
• Case Material: AISI 304 stainless steel
• Tip Material: PPS plastic
• Resistance: 5.9 ± 0.9 ohms
• Weight: 14-150g (0.5-5.3oz)

Performance Highlights

• Temperature Range: -52°C to +177°C
• Max Torque: 33.9 N•m (300 in•lb)
• Thread Engagement: 0.563 in max
• Seal Material: Viton O-ring
• Cable Type: 75 Ω coaxial FEP

Package & Support

• 12-month warranty
• Global shipping: FedEx, UPS, DHL
• Standard cable protection
• Made in USA quality

Technical FAQs

• Q: What’s the main difference between NSv and XL probes?
  A: NSv has smaller 3/8″ thread for compact spaces
• Q: Is this model pressure tested?
  A: No, contact us for custom pressure testing
• Q: Can I use below -34°C?
  A: Not recommended – may damage seal
• Q: What cable comes with 330908-12-18-70-02-00?
  A: 7m standard coaxial cable
• Q: Maximum installation torque?
  A: 11.3 N•m recommended (100 in•lb)

Get Your Resources

Download these essential documents:

• • Installation Guide for 330908-12-18-70-02-00
  • NSv Series Technical Specifications
