Bently Nevada 3300 XL 25mm Proximity Probe: Heavy-Duty Industrial Sensor

Description

The Bently Nevada 3300 XL 330851-02-000-080-10-01-00 proximity probe combines high-temperature resilience with rugged design for steam turbines and industrial machinery. Features a PEEK sensor tip and stainless steel armor, ensuring reliable performance in extreme conditions up to 200°C (392°F). Direct replacement for 7200 series probes.

Technical Data

• Brand: Bently Nevada
• Model: 3300 XL 25mm (Full suffix: 330851-02-000-080-10-01-00)
• Suffix Details:
  02=M30x2 Threaded Case
  000=0″ Unthreaded Length
  080=80mm Overall Length
  10=1.0m Cable
  01=SST Armor
  00=No Approvals
• Accuracy: 6.2Ω ±0.5 (Center-to-Outer Conductor)
• Signal: 75Ω Triaxial PFA FluidLoc Cable
• Temp Range: -35°C to +200°C (Continuous), 250°C (24h max)

Installation Guide

• Max Torque: 68 N•m (50 ft•lb)
• Case Material: AISI 304 SST
• Weight: 330g (with armor)

Compatibility

Replaces 7200 series 25mm/35mm probes (including side/rear exit). Compatible with intrinsic safety barriers (Drawing 141092).

Certificated

• FCC Part 15
• EN 61000-6-2/4
• RoHS
• ABS Maritime
