330101-00-08-05-12-CN | Bently Nevada 3300 XL 8 mm Proximity Probe

🔧 Key Features & Benefits

The Bently Nevada 330101-00-08-05-12-CN is a heavy-duty 8 mm vibration probe with built-in FluidLoc leak-proof cable. Designed for machinery monitoring in oily/wet environments. 1-year warranty included.

📏 Configuration Breakdown

• Model: 330101-00-08-05-12-CN
• Case: 0.8 in (Code 08)
• Cable: 1.6 ft with FluidLoc (Code 12)
• Thread: 3/8-24 UNF
• Certifications: Country-specific (Code CN)

🛡️ Durability First

• TipLock+: 75 lb pull-resistant bond
• FluidLock Tech: Prevents oil leaks (standard)
• Case Material: AISI 303/304 stainless steel
• Weight: 11.4 oz/m (323 g/m)

⚙️ Critical Performance Data

• Resistance: 7.45Ω ±0.50 (0.5m cable)
• Operating Temp: -62°F to +350°F (-52°C to +177°C)
• Max Cable Heat: +500°F (+260°C)
• Measure Range: 0.25-2.3mm (10-90 mils)

📜 Certifications & Support

• Humidity Test: <3% error after 56 days at 93% RH
• Wiring Guide: Use 16-24 AWG cables (max 1000 ft)
• Included: COO certificate (optional add-on)
• Pressure Seal: Viton® O-ring (custom tests available)
