Product Overview
- Brand: Bently Nevada
- Model: 330101-00-48-50-02-05
- Type: 3300 XL 8mm Probe
- Origin: Made in U.S.A
Core Configuration
- Thread Type: 3/8-24 UNF
- Armor: Without armor
- Overall Case Length: 4.8 in
- Total Cable Length: 5.0 meters (16.4 ft)
330101-00-48-50-02-05 Suffix Code Structure
- 330101
- 00 → Unthreaded Length: 0.0 in
- 48 → Case Length: 4.8 in
- 50 → Cable Length: 5.0 m
- 02 → ClickLoc™ Mini Coax Connector
- 05 → CSA / ATEX / IECEx Approval
Electrical Performance
- DC Resistance (5 m): 8.73 Ω ±0.50
- Output Range: -1 Vdc to -17 Vdc
- Linear Range: 0.25 mm to 2.3 mm
- Recommended Gap: 1.27 mm (50 mils)
- Sensitivity: 7.87 V/mm
Mechanical Strength
- Probe Tip: PPS material
- Case: AISI 303 / 304 Stainless Steel
- Pull Strength: 330 N (75 lbf)
- Weight: 323 g/m
Environmental Ratings
- Operating Temp (Standard): -52°C to +177°C
- Extended Temp Tip: up to +218°C
- Cable Temp Limit: +260°C
- Humidity Drift: < 3% at 93% RH
Key Advantages
- High resistance to vibration shock
- Stable signal over long distance
- Oil-leak prevention design
- Easy field replacement
- Works with 3300 XL 8mm Proximity Probe systems
Warranty & Shipping
- Warranty: 12 Months
- Shipping Methods:
- FedEx
- UPS
- DHL
Professional FAQ
Q1: Is this probe suitable for high vibration areas?
A1: Yes. The 8 mm body offers higher mechanical strength.
Q2: Can this probe work with older 3300 systems?
A2: Yes. It is backward compatible with 3300 XL systems.
Q3: How do I choose cable length?
A3: Measure total distance. Do not mix different length systems.
Q4: Is FluidLoc cable required?
A4: Only if oil leakage through cable is a concern.
Q5: What gap gives best accuracy?
A5: Set around 1.27 mm for stable radial vibration reading.
