330101-29-52-05-02-05 | Bently Nevada 3300 XL 8 mm Proximity Probe

Heavy-Duty Vibration Sensing Solution

The Bently Nevada 330101-29-52-05-02-05 combines an extended 5.2″ stainless steel case with a 2.9″ unthreaded section for deep machine installations. Certified for explosive areas (ATEX/IECEx) and backed by a 1-year warranty.

Part Number Decoded

• 330101-29-52-05-02-05
• 29 – 2.9″ unthreaded section
• 52 – 5.2″ case (extra-long)
• 05 – 1.6 ft (0.5m) cable
• 02 – ClickLoc connector
• 05 – Hazardous area certified

Core Performance Data

• Temp range: -62°F to +350°F (-52°C to +177°C)
• Cable grip: 75 lb pull tested
• Accuracy: ±1 mil (0.025mm)
• Resistance: 7.45Ω ±0.50

Extended Reach Design

Built for challenging installations:
– 5.2″ case length reaches deep into machinery
– 2.9″ unthreaded section for secure mounting
– PPS plastic tip resists chemical wear
– Viton® O-ring prevents fluid ingress

Key Specifications

• 69.9 pF/m cable capacitance
• 323 g/m (11.4 oz) weight
• Supports 1,000 ft cabling
• 93% humidity tolerance (56 days)
• Optional FluidLoc leak protection

Certifications & Support

• ATEX/IECEx/CSA certified
• Made in USA with COO available
• Extended temp to +425°F (tip)
