330105-02-12-20-02-00 | Bently Nevada | 3300 XL 8mm Reverse Mount Probe

Product Identification

Manufacturer: Bently Nevada | Made in U.S.A 330105-02-12-20-02-00 | 3300 XL 8mm Reverse Mount Probe
Suffix Breakdown: -20 (2.0m/6.6ft) | -02 (ClickLoc) | -00 (No Certifications Required)

Critical Specifications for 330105-02-12-20-02-00

• • 7.88Ω ±0.50 DC resistance @2.0m | 75Ω triaxial FEP/PFA cable
• • 323g/m (11.4oz/ft) mass | Thread: 3/8-24 UNF (14.3mm max grip)
• • Tensile: 330N case-to-lead | 270N connector safety limit

Material Composition

• • PPS Sensor Tip | Corrosion-resistant SST303/304 housing
• • Cable Options: 0.5-9m standard FEP | 0.5-9m extended PFA
• • Armor Upgrade: Flexible SST302/304 with FEP protection

Operational Boundaries

• • -52°C to +177°C standard thermal range
• • High-Temp Mode: +218°C tip/+260°C cable endurance
• • Humidity: <3% ASF drift @93% RH (IEC 68-2-3 compliant)
• • Pressure: Viton® O-ring barrier (factory non-tested)

Compliance & Assurance

• Certification-Free (-00 suffix) | 1-Year Full Warranty
• Cold Warning: Avoid <-34°C to prevent seal degradation

Installation Guidelines

• • ClickLoc-02 connector ensures secure coaxial interface
• • Standard FEP cable suitable for 99% of reverse-mount applications
• • Pressure testing available via special engineering request

Document Download Here:3300 XL 8 mm Proximity Transducer System Datasheet
