330106-05-30-90-02-CN – Nevada | 3300 XL 8mm Proximity Probe

Bently Nevada 330106-05-30-90-02-CN 3300 XL 8 mm Reverse Mount Probe

Basic Details

• Part Number: 330106-05-30-90-02-CN
• Thread Type: M10 x 1
• Total Length: 9.0 meters (29.5 feet)
• Connector: Miniature ClickLoc coaxial
• Approval Code: CN (Country Specific)
• Tip Material: PPS plastic
• Case Material: Stainless Steel (303 or 304)
• Resistance: 9.87 ± 0.50 ohms

Performance Info

• Signal: Eddy current
• Cable: 75Ω triaxial, FEP or PFA insulated
• Armor Option: SST with FEP cover
• Connector Metal: Gold-plated brass or beryllium copper
• Pull Strength: 330 N (probe), 270 N (cable)

Temperature Range

• Standard Use: -52°C to +177°C
• Extended Tip: -52°C to +218°C
• Extended Cable: -51°C to +260°C

How to Install

• Mount using M10 x 1 threaded port
• Thread depth should not pass 15 mm
• Clean and dry the surface before use

Works With

• 3300 XL monitoring systems
• Proximitor and extension cables
• Reverse mount setups with tight access

Shipping Methods

• FedEx
• UPS
• DHL

Full Model Breakdown

• 330106: 8 mm reverse mount probe
• 05: 9 m cable
• 30: Steel target
• 90: 9 m total length
• 02: Mini ClickLoc connector
• CN: Country-specific approvals
