330130-045-10-05 Bently Nevada – 3300 XL 8mm Extension Cable

Bently Nevada 330130 Sensor Cable

Key Features

Model 330130-045-10-05 is a 4.5m oil-proof cable with CSA/ATEX safety certifications. Made in USA. 1-year warranty. Optional COO document available.

Basic Specs

• Length: 4.5m (14.8ft)
• Weight: 0.618kg
• Wire Resistance: 0.99Ω (core) / 0.30Ω (shield)
• Voltage: -17.5V to -26VDC
• Temp Range: -40°C to +125°C

Oil Protection

Special FluidLoc seal stops machine oil leaks. Works with all 3300 XL 8mm probes. Uses heavy-duty O-rings. Not tested for pressure before shipping.

Easy to Install

• Works with 16-24 AWG wires
• Keep 1.27mm gap from metal targets
• Includes repair tape (don’t use in oil areas)
• Max cable run: 305 meters

Reliable Performance

Handles wet air (93% humidity) for 56 days. Strong 330N pull resistance. Works at high locations (2000m).

Power Needs

Use 3-wire shielded cables. Stable output (50Ω). Best results below -23.5VDC. Measures 0.25-2.3mm gaps.

What’s Included

Armored cable, connector parts, sealing tape. Ask about pressure testing services.

Warranty

1-year protection for your 330130-045-10-05 cable. Perfect for oil machines.
