330171-00-30-10-02-00 | Bently Nevada 5mm Proximity Probe

Bently Nevada 330171-00-30-10-02-00 – Compact 5mm Vibration Sensor

Decoding 330171-00-30-10-02-00

• ├─ 330171 → 5mm probe series
• ├─ 00 → 0″ unthreaded section
• ├─ 30 → 3.0″ case length
• ├─ 10 → 1.0m cable
• ├─ 02 → ClickLoc connector
• └─ 00 → No special approvals

Technical Highlights

• Thread size: 1/4-28 UNF (max 0.375″ deep)
• Power: -17.5V to -26V DC @ 12mA max
• Resistance: 7.59Ω ±0.50 (center to outer)
• Cable type: 75Ω triaxial FEP
• Pull strength: 222N (50lbs) at both ends
• Bend radius: ≥25.4mm (1″)

Installation Made Easy

• 🔧 Use #3 drill bit or larger
• 🔩 Tighten to 5.1 N·m (45 in-lb) – never exceed 7.3 N·m
• 📏 Keep 1.27mm (50 mils) gap from target
• ⚠️ Don’t bend cable sharply near probe

Expert FAQs

• Q: Can I use this in steam environments?
  A: Yes, PPS tip handles steam well
• Q: What’s the vibration range?
  A: Measures up to 50 mils (1.27mm)
• Q: Is calibration needed?
  A: Comes pre-calibrated for 4140 steel
• Q: Can I repair damaged cables?
  A: No, cable damage requires replacement
• Q: How fast does it respond?
  A: <10μs response time for most vibrations

Package Contents

• 1× 5mm vibration probe
• 1× Connector protector
• 1× Installation guide

Order & Support

• 🚚 Ships via FedEx/UPS/DHL
• 12-month quality guarantee
• 🇺🇸 Made in USA
