330191-00-08-50-CN 3300 XL 8 mm ETR Probe Bently Nevada Without Armor

Overview

This 5.0-meter industrial probe (330191-00-08-50-CN) monitors machinery in plants requiring country-specific safety approvals. Designed for power generation and mining, it handles extreme heat/cold with a stainless steel body and PPS plastic tip. The FluidLoc option blocks oil leaks, while 75Ω triaxial cables ensure stable signals.

Technical Specifications

• Brand: Bently Nevada
• Model: 330191-00-08-50-CN
• Model Code Guide:
  • 330191 ▷ Base product line
  • -00 ▷ Standard features
    • This variant: -CN = Local country certification
  • -08 ▷ Compact design
    • Case length: 0.8″ (20.3mm)
    • Thread: 3/8-24 UNF
  • -50 ▷ 5.0m (16.4ft) cable length
  • -CN ▷ Meets local regulations
• Electrical Performance:
  • Voltage: -17.5VDC to -26VDC (±0.3V)
  • Current: 12mA standard / 18mA with barriers
  • Resistance: 8.73Ω ±0.50 @25°C
• Durability:
  • Cable pull strength: 75lbf (330N)
  • Thread torque: 5in·lbf (0.565N·m)
  • Weight: 11.4oz/ft (323g/m)
• Temperature Range:
  • Continuous: -55°C to +232°C
  • Short-term: +280°C for 60 minutes

Package Includes

• Probe with 5.0m FEP cable
• 3/8-24 UNF mounting hardware
• Calibration certificate (traceable to NIST)
• Warranty: 12 months
