330500-03-00 | 330500 – Velomitor Piezo-velocity Sensor Bently Nevada

Bently Nevada Velomitor Piezo-Velocity Sensor

Summary

The 330500-03-00 provides precise vibration monitoring with 3.94mV/mm/s sensitivity and 5kHz frequency response. Its 316L stainless steel housing and 1/4-28 UNF thread suit general industrial applications without hazardous-area certifications.

Key Specifications

• Sensitivity: 3.94mV/mm/s ±5% (100Hz calibrated)
• Velocity Range: 0.004–1270 mm/s peak
• Shock Survival: 5,000g peak impact

Model Suffix Breakdown: 330500-03-00

Mechanical Profile

┌──────────────────────┬───────────────────────────┐
│ Mounting Thread      │ 1/4-28 UNF                │
│ Torque Specification │ 24-40 in-lb (32-46 kg cm) │
│ Case Material        │ 316L stainless steel      │
│ Sealing              │ Hermetic (IP68-grade)     │
└──────────────────────┴───────────────────────────┘

Compliance

• FCC Part 15 – EMI compliance
• EMC Directive 2014/30/EU
• RoHS 2011/65/EU
• DNV marine standards (non-certified)

Typical Applications

• Industrial pumps in non-hazardous areas
• HVAC system vibration monitoring
• General manufacturing equipment
