330702-00-10-90-02-05 | Bently Nevada11 mm Proximity Probe

Bently Nevada 3300 XL 11mm Proximity Probe – 9m Cable Version

Product Highlights

• Extra-long 9 meter (29.5 ft) triaxial cable
• Works in extreme temperatures (-51°C to +177°C)
• Armored stainless steel construction
• ClickLoc connector for secure connection

Model Number Breakdown

• 330702 – Base model (3300 XL 11mm)
  • 00 – 0.0″ unthreaded length
  • 10 – 1.0″ case length
  • 90 – 9.0 meter cable
  • 02 – Standard cable with ClickLoc
  • 05 – Multiple approvals

Key Specifications

• Thread size: 1/2-20 UNF
• Cable resistance: 8.5Ω ±1.1
• Max torque: 45.2 N•m (400 in-lb)
• Min bend radius: 25.4mm (1.0″)
• Shipping weight: 0.17kg

Installation Guide

• Max thread engagement: 0.75″
• Recommended torque: 15.2 N•m
• Connector torque: Finger tight only

5 Professional FAQs

• Can I use this 9m probe with 1m systems? No – requires matching 9m system
• Is the cable oil-resistant? Yes – FEP insulation resists fluids
• What’s the max pressure rating? Contact us for pressure testing
• Can I cut the cable shorter? Not recommended – will affect calibration
• How often should probes be replaced? Typically 3-5 years depending on use

What’s Included

• 1x 3300 XL 11mm probe (330702-00-10-90-02-05)
• 9m triaxial cable with ClickLoc connector

Support & Shipping

• 12 month product warranty
• Fast shipping via FedEx, UPS, or DHL
