330708-00-10-90-11-05 | Bently Nevada 3300 XL 11 mm Proximity Probe

Bently Nevada 3300 XL Proximity Probe – Precision Vibration Sensor (Model 330708-00-10-90-11-05)

Industrial-grade 11mm vibration probe for machine health monitoring. U.S. made with multiple agency approvals. Ships fast worldwide.

Model Number Decoder

• ▸ 330708: Base model (11mm, 5/8-18 UNF)
• ▸ 00: No unthreaded section
• ▸ 10: 1.0 inch case length
• ▸ 90: 9 meter cable
• ▸ 11: ClickLoc connector with protector
• ▸ 05: Multiple agency approvals

Key Specifications

• Size: 11mm diameter
• Cable: 9m FEP-insulated triaxial
• Resistance: 5.9Ω ±0.5 (center to outer)
• Thread: 5/8-18 UNF (0.938″ max engagement)
• Case Torque: 15.2 N•m recommended (45.2 N•m max)
• Bend Radius: Minimum 25.4mm
• Shipping Weight: 0.17kg

Product Support

• Warranty: 12 months parts coverage
• Shipping: FedEx/UPS/DHL express available
• Certificates: COO available on request

Get Started

• Download Installation Guide
• View Technical Drawings

Expert Questions Answered

• Q: What approvals does this model have?
  A: ATEX, IECEx, and more (suffix -05)
• Q: Can I use this in explosive areas?
  A: Yes, it’s approved for hazardous locations
• Q: How durable is the cable?
  A: FEP insulation resists oils and chemicals
• Q: What’s the difference between -11 and -12 connectors?
  A: -11 has a protective cover, -12 doesn’t
• Q: Can I get shorter cables?
  A: Yes, we stock 1m and 5m versions too
