Bently Nevada 330901-00-12-70-02-00 Proximity Probe
Product Overview
This is a 3300 NSv proximity probe made in the U.S.A. It features a 1.2-inch case length and a 7-meter cable with a miniature coaxial ClickLoc connector. It has a 1/4-28 UNF thread and no armor.
Technical Specifications
- Model: 330901-00-12-70-02-00
- Thread Size: 1/4-28 UNF
- Unthreaded Length: 0 in
- Case Length: 1.2 in
- Cable Length: 7.0 meters (23.0 feet)
- Connector Type: Miniature coaxial ClickLoc, standard cable
- Agency Approval: Not required
- Case Material: AISI304 stainless steel
- Tip Material: Polyphenylene sulfide (PPS)
- Cable Specs: 75 Ω coaxial, FEP insulated
- Probe DC Resistance: 5.9 ± 0.9 ohms (7 m cable)
- Pressure Seal: Viton O-ring
- Weight: Approx. 14 to 150 g (0.5 to 5.3 oz)
Installation Guide
- Max thread engagement: 0.375 in
- Avoid long exposure below -34°C to protect seal
Model Code Breakdown
- 330901 – 3300 NSv probe series
- 00 – Unthreaded length 0 in
- 12 – Case length 1.2 in
- 70 – Cable length 7.0 m
- 02 – Mini coaxial ClickLoc connector, standard cable
- 00 – No agency approval needed
Industrial Benefits
- Compact size fits tight spaces
- Strong resistance to vibration and heat
- Easy to install with standard connectors
Shipping
Fast delivery via FedEx, UPS, or DHL with tracking.
