330908-00-15-05-02-00 Bently Nevada 3300 NSv Proximity Probe Sensor

Product Overview

• 330908-00-15-05-02-00 is a compact industrial proximity probe.
• Manufactured by Bently Nevada.
• Part of the NSv Probes series.
• Used for shaft vibration and displacement measurement.
• Designed for small machine spaces.
• Strong chemical resistance improves durability.
• Stable signal supports accurate monitoring.
• Available in stock with fast delivery.

• Download the installation manual before use.
• The manual explains probe gap, wiring, and calibration steps.

Configuration Tree Structure

• Model Number Structure
• • 330908
    • Series: 3300 XL NSv Proximity Probes
    • Thread: 3/8-24 UNF
    • Probe without armor
  • 00
    • Unthreaded probe length
    • 0 inch
  • 15
    • Probe case length
    • 1.5 inch
  • 05
    • Total cable length
    • 0.5 meter
  • 02
    • Miniature coaxial ClickLoc connector
    • Standard probe cable
  • 00
    • No certification option required

Main Technical Specifications

• Brand: Bently Nevada
• Model: 330908-00-15-05-02-00
• Series: 3300 XL NSv Proximity Probes
• Probe Thread: 3/8-24 UNF
• Cable Length: 0.5 m
• Probe Case Length: 1.5 in
• Linear Range: 1.5 mm
• Recommended Gap: 1.0 mm
• Incremental Scale Factor: 7.87 V/mm
• Linearity Deviation: ±0.06 mm
• Frequency Response: 0–10 kHz
• Probe Resistance: 4.0 ±0.5 Ω
• Target Diameter: minimum 8.9 mm
• Recommended Target: 13 mm
• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• Minimum Bend Radius: 25.4 mm
• Probe Tip Material: Polyphenylene sulfide
• Probe Case Material: AISI 304 stainless steel
• Cable Type: 75 Ω coaxial FEP insulated cable

Electrical Cable Characteristics

• Center conductor resistance: 0.220 Ω/m
• Shield resistance: 0.066 Ω/m
• Cable capacitance: 69.9 pF/m
• Maximum field wiring length: 305 m
• Recommended shielded triad cable.

Diagnostic Capability

• Detect shaft vibration changes.
• Monitor axial displacement.
• Identify imbalance in rotating equipment.
• Detect misalignment problems early.
• Support predictive maintenance programs.

Typical Equipment Applications

• Process compressors
• Small steam turbines
• Industrial pumps
• Gearboxes
• Precision rotating machines

Manager’s Insight

• The NSv probe is designed for tight installation spaces.
• It provides strong chemical resistance.
• Engineers prefer it in compressor monitoring systems.
• The short body simplifies mounting.
• Reliable signal helps protect rotating assets.

Packaging and Delivery

• 1 × 330908-00-15-05-02-00 proximity probe
• Factory original sealed packaging
• Quality inspection before shipment
• 12-month warranty
• Dispatch within 12-48 hours
• Courier partners: FedEx, UPS, DHL

Model Selection Comparison

• 330908-12-36-05-02-00
• Longer probe configuration for different mounting depth.

• 330908-12-31-70-02-05
• Long cable option for remote installation.

FAQ

• Why choose the NSv probe instead of RAM probes?
• NSv probes offer better chemical resistance.
• What is the best gap distance for stable output?
• The recommended gap is 1.0 mm.
• Can the probe work with older Bently systems?
• Yes. It is compatible with earlier 3300 RAM systems.
• What happens if the target is too small?
• The scale factor may change slightly.
• How to reduce signal noise during installation?
• Use shielded triad cable and proper grounding.
