Bently Nevada 330908-12-08-05-02-00 NSv Proximity Probe
Overview
This is a compact proximity probe for use in tight areas. It belongs to the 3300 NSv series. The model includes a 0.5-meter cable with a small ClickLoc connector. It has no armor.
Main Features
- Thread: 3/8-24 UNF
- Tip Length: 1.2 in
- Case Length: 0.8 in
- Cable Length: 0.5 meter
- Connector: Mini ClickLoc
- Cable Type: 75 Ω coaxial, FEP-insulated
- Approvals: Not required
Materials
- Case: AISI304 stainless steel
- Tip: Polyphenylene sulfide (PPS)
Electrical Info
- Resistance at 0.5 m: 4.0 ± 0.5 ohms
Torque & Mounting
- Max Torque: 33.9 N·m
- Recommended Torque: 11.3 N·m
- Thread Limit: 0.563 in
Temperature
- Working Range: -52°C to +177°C
- Storage Range: -52°C to +177°C
- Note: Long exposure below -34°C may damage the seal
Sealing & Pressure
- Seal Type: Viton O-ring
- Pressure Test: Not done at factory
Weight
- 14 to 150 g
Model Breakdown
- 330908: NSv series probe, 3/8-24 UNF
- 12: Tip length 1.2 in
- 08: Case length 0.8 in
- 05: 0.5-meter cable
- 02: Mini ClickLoc connector
- 00: No agency approval
Included Items
- 1 × Proximity Probe (330908-12-08-05-02-00)
- 0.5 m cable attached
Shipping & Warranty
- Shippers: FedEx, UPS, DHL
- Dispatch Time: Ships within 1–2 business days
- Warranty: 12 months (standard replacement)
