330908-12-46-70-02-05 3300 NSv Proximity Probes Without Armor

Bently Nevada 3300 NSv Long-Reach Probe – 7m Industrial Sensor

Extended 4.6-inch body proximity probe with 7-meter cable. Multiple global approvals included. Made in USA.

Product Configuration

• Base Model: 330908 (3300 NSv Probe)
• Unthreaded: 12 = 1.2 inches
• Case Length: 46 = 4.6 inches
• Cable Length: 70 = 7.0 meters
• Connector: 02 = ClickLoc standard
• Approvals: 05 = Multiple agencies

Technical Highlights

• 7m FEP cable for distant equipment
• 3/8-24 UNF thread with 0.563″ max depth
• Electrical resistance: 5.9Ω ±0.9Ω
• Weight range: 14-150g (0.5-5.3oz)
• Coaxial cable: 75Ω with FEP insulation

Performance Data

• Temp Range: -52°C to +177°C
• Case Torque: Max 33.9 N•m (300 in•lb)
• Recommended Torque: 11.3 N•m (100 in•lb)
• Min Temp Warning: Avoid below -34°C
• Seal Type: Viton O-ring

Mounting Guide

• Max thread engagement: 0.563 inch
• Use torque wrench for installation
• Standard cable requires careful handling
• Pressure testing available on request

Service & Delivery

• 12-month warranty
• Worldwide shipping: FedEx/UPS/DHL
• Certificate of Origin available
• Made in USA quality

Technical Questions

• Q: What is the case length exactly?
  A: 4.6 inches total length
• Q: Does this model have armor protection?
  A: No, standard cable without armor
• Q: What is the probe tip material?
  A: Polyphenylene sulfide (PPS)
• Q: Can I use this in hazardous areas?
  A: Yes, multiple approvals included
• Q: What is the cable’s bend radius?
  A: Minimum 25.4mm (1 inch)

Download Complete Documentation

Get full specifications for your 330908-12-46-70-02-05 probe:

• • Installation Guide
  • Technical Datasheet
