Overview
- Manufacturer: Bently Nevada
- Product Number: 3500/94M 120M8155-01
- Display Type: Advantech 10″ Industrial Monitor
- Model: ANA-D3510-100-A1
- Made in U.S.A.
- Designed for 3500/94M system visualization.
- Mounting screws are not included.
- Built for continuous industrial operation.
- Warranty: 12 months.
Configuration Breakdown
- 3500/94M
- Display platform series
- 120M8155
- Advantech display hardware package
- Industrial touch monitor configuration
- 01
- Hazardous area approval option
- North America certification enabled
Industrial Display Highlights
- 10-inch LED backlit LCD screen.
- Clear graphics in bright environments.
- Resistive touch supports gloves operation.
- Industrial hardened enclosure.
- Stable long-term performance.
- Low power consumption design.
- Wide mounting flexibility.
- Suitable for hazardous locations.
Display and Electrical Data
- Screen Size: 10 inch diagonal
- Touch Screen Size: 267 mm
- Display Type: LCD with LED backlight
- Supply Voltage: 24 Vdc included
- Permissible Voltage Range: 10–28 Vdc
- Operating Current: < 500 mA
- Inrush Current: 3.5 A at 24 Vdc
- Power Stability: Industrial regulated input
- Response Accuracy: Fast touch detection
- Backlight Lifetime: Extended industrial grade
Mechanical Design
- Dimensions: 249 × 389 × 48 mm
- Panel Cutout: 342.9 × 228.6 mm
- Weight: 4.0 kg shipping
- Compact depth saves cabinet space.
- Front sealing supports IP54 protection.
Environmental Performance
- Operating Temperature: −20°C to 65°C
- Storage Temperature: Industrial rated
- Humidity Range: 10%–85% RH non-condensing
- Dust and water spray protection.
- Heated enclosure required below −20°C exposure.
Mounting Flexibility
- Face mount installation
- 19 inch rack mounting
- Panel mounting option
- Independent mounting support
- Easy integration into operator stations.
Hazardous Area Certifications
- Class I Division 2 Groups A, B, C, D T4
- CSA C22.2 certified
- ISA 12.12.01 compliant
- UL60079 industrial approval
- ATEX / IECEx Zone 2 certified
- Temperature Class T4 protection
- IP54 enclosure protection rating
Additional Technical Advantages
- Designed for vibration monitoring systems.
- Stable display during electrical noise.
- Improved operator interaction speed.
- Long service lifecycle components.
- Reliable industrial touch response.
- Optimized for continuous monitoring rooms.
Shipping and Warranty
- Factory original packaging.
- 12-month warranty coverage.
- Global delivery available.
- Courier services: FedEx, UPS, DHL.
Professional FAQ
- Q: Is this display suitable for hazardous plants?
- A: Yes. It supports Class I Division 2 and ATEX Zone 2 environments.
- Q: Why choose resistive touch instead of capacitive?
- A: Resistive screens work with gloves and dirty environments.
- Q: What should buyers confirm before ordering?
- A: Check mounting size and system compatibility.
- Q: Can this monitor run continuously?
- A: Yes. It is designed for 24/7 industrial operation.
- Q: When is a heated enclosure needed?
- A: When ambient temperature drops below −20°C.
