AGS813-S10 Yokogawa Servo Module | AGS813 Isolated I/O Control

Oiltech Controls Limited’s Insight

• The Yokogawa AGS813-S10 is a high-performance Turbomachinery I/O Module engineered specifically for precision steam and gas turbine governing. Unlike standard analog cards, the AGS813-S10 integrates LVDT excitation and demodulation directly with a high-speed 5ms scan cycle. This eliminates the latency typical of external signal converters, providing the deterministic response required for critical surge protection and speed control loops. For engineers managing aging hydraulic actuators, the dual-range ±25mA/±50mA output offers the necessary flexibility to drive a wide variety of servo valves without additional amplification hardware.

Configuration Breakdown & Suffix Tree

• AGS813 — Series Identifier: Servo Modules (Isolated Type)
  •         ∟ -S — Functional Specification: Standard Type
    •                 ∟ 1 — Fixed Designation: Always 1 (Standard Revision)
      •                         ∟ 0 — Hardware Build: Basic Type Configuration

Technical Data Hierarchy

• Scan Cycle Performance: Ultra-fast 5ms processing for real-time control.
• LVDT Feedback (4-Channel):
  • ∟ Wiring Compatibility: Support for 3-wire, 5-wire, and 6-wire sensors.
  • ∟ Excitation Source: 5Vrms with selectable frequencies (2.8k, 3.0k, 3.2kHz).
  • ∟ Accuracy: ±1% (0.7 to 5 Vrms range).
• Standardized Voltage Input (4-Channel):
  • ∟ Range: 1 to 5V DC isolated signals.
  • ∟ Precision: ±4 mV accuracy with high 1 MΩ impedance.
• Servo Output & Actuation:
  • ∟ Selectable Ranges: ±25 mA or ±50 mA independently configurable.
  • ∟ Dither Injection: 0 to ±20% at 33 Hz to prevent valve stiction.
  • ∟ Load Resistance: Up to 270 Ω (at 25mA) or 100 Ω (at 50mA).
• Physical & Electrical Safety:
  • ∟ Isolation Barrier: 500V AC withstanding voltage (System to Field).
  • ∟ Power Draw: 500 mA at 5V DC internal; 0.3A at 12V DC external.

Diagnostics & Protection

• Circuit-Open Detection: Automatic monitoring of output loops to prevent “runaway” valve conditions.
• Thermal Stability: Low drift of ±0.4%/10°C ensures setpoint integrity in high-heat turbine halls.
• Collective Filtering: Integrated hardware filtering to suppress high-frequency EMI from large motor starters.

Compatibility & Equipment Fit

• Steam Turbine Governors: Controlling electro-hydraulic actuators (EHA).
• Gas Turbine Fuel Skids: Precise positioning of fuel gas control valves (FGCV).
• LVDT Sensors: Compatible with major brands like Schaevitz, TE Connectivity, and AMETEK.
• Cabling: Requires dedicated AKB337-M005/M007/M010 cable assemblies for secure field termination.

Logistics & Warranty Terms

• Dispatch Timeline: Ships within 24-48 Hours from our global hub.
• Shipping Methods: Rapid delivery via FedEx, UPS, or DHL Express.
• Warranty Coverage: Full 12-Month Quality Assurance against manufacturing defects.
• Condition: Brand New Original factory-sealed units only.

Advanced FAQ & Selection Guide

• How does the dither function on the AGS813-S10 improve valve life?
  The dither applies a small 33Hz oscillation to the output. This keeps the servo valve spool in constant micro-motion, effectively preventing static friction (stiction) caused by hydraulic fluid contaminants.
• Can I mix LVDT and 1-5V signals on the same AGS813-S10 module?
  Yes. The module handles 4 channels of LVDT and 4 channels of Voltage inputs simultaneously. However, the 1-5V signals are typically used for secondary position transmitters if an LVDT is not available.
• What is the critical factor when selecting the AKB337 cable length?
  Since the AGS813-S10 uses low-voltage excitation (5Vrms), long cable runs can lead to voltage drops. We recommend the M005 (5m) or M007 (7m) for high-accuracy feedback loops to maintain signal SNR.
• Is an external power supply mandatory for operation?
  Yes. While the system logic runs on 5V DC, the LVDT excitation and Current Outputs require a stable +12V DC (0.3A) external supply to function correctly.
• What happens if the LVDT excitation frequency is mismatched?
  A mismatch will cause phase shift errors in the demodulator, leading to “noisy” feedback. Always match the AGS813-S10 selectable frequency (2.8k to 3.2kHz) to the sensor manufacturer’s specific data sheet.
