1734-AENTRK POINT I/O Adapter
The 1734-AENTRK is a conformally coated EtherNet/IP adapter for POINT I/O systems. It supports up to 63 modules and multiple network topologies. This in-cabinet unit offers reliable communication for industrial automation. Its compact DIN-rail design saves panel space.
Technical Specifications
| Brand | Allen-Bradley |
| Model | 1734-AENTRK |
| Type | Network Adapter, POINT I/O |
| Communication Protocol | EtherNet/IP |
| Module Capacity | 63 modules (PointBus) |
| Supported Topologies | Star, Tree, Linear, Ring |
| Mounting | DIN Rail |
| Power Supply | 24V DC |
| Temperature Range | -20 °C to 55 °C (-4 °F to 131 °F) |
| Enclosure | Open-style (no GX rating) |
| Special Feature | Conformal Coated (humidity/dust resistance) |
- Measurement Range: Digital I/O, up to 63 nodes
- Frequency Response: 100 Mbps EtherNet/IP
- Sensitivity: High noise immunity for industrial environments
- Linearity: Maintains signal integrity across the network
- Resolution: 16-bit internal processing
- Environmental Tolerance: -20 °C to 55 °C, conformal coated for moisture protection
- Interference Immunity: Built-in EMC protection, shields against RFI/EMI
- Diagnostic Capabilities: LEDs for status, network activity, and fault detection
Installation & Maintenance
- Mounting: Snap-on DIN rail. No tools required for quick installation.
- Wiring: Removable terminal blocks for easy connections.
- Commissioning: Auto-addressing via RSNetWorx or Studio 5000.
- Maintenance: Hot-swappable modules reduce downtime. LED indicators simplify troubleshooting.
Compatibility & Certifications
- Works with all POINT I/O modules (1734 series).
- Integrates with Modicon Quantum and other PLC systems via EtherNet/IP.
- Supports Rockwell Automation Logix, CompactLogix, and ControlLogix.
- Certifications: CE, UL, cULus, and ATEX for hazardous locations (pending).
Typical Applications
- Distributed I/O in assembly lines and conveyor systems.
- Process control in chemical and water treatment plants.
- Packaging machines and material handling systems.
- Retrofit of legacy systems requiring EtherNet/IP connectivity.
- Remote I/O for robotics and motion control cells.
Diagnostic & Troubleshooting
- LED Indicators: Module status, network activity, link/activity, and fault.
- Web Server: Built-in diagnostics page for IP configuration and health monitoring.
- Alarm: Configurable alerts for communication loss or overload.
- Logging: Event log via RSLogix 5000 for predictive maintenance.
Frequently Asked Questions
- Q: Does this adapter support ring topology?
Yes, it supports Device Level Ring (DLR) for redundancy. - Q: Is conformal coating necessary?
It protects against moisture, dust, and chemical vapors – ideal for harsh environments. - Q: Can I use it with third-party PLCs?
Yes, as long as they support EtherNet/IP and implicit messaging. - Q: What is the maximum cable length?
100 meters per segment (copper). Use fiber for longer distances.
Packaging & Warranty
- Package Includes: 1734-AENTRK adapter, terminal block, and user manual.
- Warranty: 12 months against manufacturing defects.
- Shipping: FedEx, UPS, or DHL express (global delivery).
- Documentation: Quick start guide and certificate of conformance.
