Allen-Bradley 1756-OV16E – Smart Fused Output Module

Key Benefits

• 🔌 16 protected outputs with electronic fusing
• 🔌 Ultra-fast 75μs ON / 360μs OFF switching
• 🔌 Wide 10-30V DC operating range
• 🔌 1A per point (8A total) capacity
• 🔌 Built-in overcurrent protection

Technical Specifications

• Model: 1756-OV16E (ControlLogix Series)
• Output Type: Electronically fused sinking
• Voltage Range: 10-30V DC
• Current Rating: 1A/point, 8A/module
• Response Time: 75μs ON, 360μs OFF
• Power Use: 210mA @ 24V DC
• Protection: 2A surge (10ms pulses)
• Temp Range: 0°C to 60°C

Protection Features

• 🛡️ Auto-resetting electronic fuses
• 🛡️ 700mV max voltage drop
• 🛡️ 1mA max leakage current

Your Protection

• 🔒 12-month satisfaction guarantee
• ✈ Fast global delivery options
• ⚡ Ready for harsh industrial environments

Expert Questions

• Q: How fast are the output responses?
  A: 75μs to turn ON, 360μs to turn OFF.
• Q: What happens during overcurrent?
  A: Electronic fuses protect each output.
• Q: Can all outputs run at 1A simultaneously?
  A: Yes, up to 8A total module current.
• Q: What’s the minimum load requirement?
  A: 2mA per point for proper operation.
• Q: Is this module humidity resistant?
  A: Yes, operates at 5-95% non-condensing.

Resources

• 📥 Download 1756-OV16E full manual
