12-Channel 240V AC Input Module for Heavy-Duty Applications
The Allen-Bradley 1769-IM12 delivers reliable AC signal monitoring for industrial control systems. Designed for CompactLogix platforms, this module handles high-voltage inputs with precision and durability.
Key Features
- 12 AC input channels with common connection
- Wide voltage range: 159-264V AC
- Fast 20ms response time
- DIN rail or panel mount options
- Built-in overload protection
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-IM12
- Input Type: 240V AC
- Voltage Range: 159-264V AC
- Frequency: 47-63 Hz
- Isolation: 1836V AC tested
- Wire Size: 22-14 AWG
- Operating Temp: 0°C to 60°C (32°F to 140°F)
- Shock Rating: 30G operational
- Humidity: 95% non-condensing
Easy Installation
- Max 8 modules from power supply
- Simple DIN rail mounting
- Clear status indicators
- Copper wiring compatible
System Compatibility
Works with:
CompactLogix controllers and
MicroLogix systems
Package Contents
- 1769-IM12 module
- Terminal block
- Mounting hardware
- Quick-start guide
Warranty & Shipping
12-month quality guarantee. Worldwide shipping via FedEx, UPS, or DHL.
Expert FAQs
- Q: Can it handle voltage spikes?
A: Yes, rated for 264V AC continuous operation. - Q: What’s the minimum input voltage?
A: 159V AC for reliable detection. - Q: How are wiring faults detected?
A: LED indicators show power and fault status. - Q: Is it suitable for motor controls?
A: Ideal for monitoring motor contactors and pumps. - Q: What’s the altitude limit?
A: Full performance up to 2000m (6561ft).
Get Complete Documentation
- Download wiring diagrams
- Access installation guides
- View full specifications:
Download Product Manual (PDF)
