Product Introduction
The Allen-Bradley 1790D-0B16 is a DeviceNet output module. It has 16 sourcing output points. This module works with CompactBlock LDX systems. It controls devices in factory automation.
Main Features
- 16 output points for device control
- Sourcing output type
- 0.5A maximum current per point
- 4.0A maximum current per common
- 10-28.8V DC operating voltage
- Fast 0.5ms response time
- Green status lights for each point
- 37-pin D-shell connector
Technical Specifications
- Brand: Allen-Bradley
- Model: 1790D-0B16
- Output Points: 16 points
- Output Type: Sourcing
- Voltage: 24V DC nominal
- Current: 0.5A max per point
- Network: DeviceNet
- Speed: 125/250/500 kbps
- Connector: 37-pin D-shell
Package & Shipping
- Includes one 1790D-0B16 module
- 12-month product warranty
- Worldwide shipping service
- FedEx, UPS, DHL available
- Fast delivery guaranteed
FAQ
- What devices can it control?
It controls relays, solenoids, and small motors.
- How many output groups?
Two groups with 8 points each.
- Power needs?
24V DC power supply required.
- Network speed?
125, 250, or 500 kbps selectable.
- Installation height?
Works up to 1000 meters altitude.
