Allen-Bradley 1756-OF8IK – High-Performance Isolated Analog Output Module
Technical Highlights
- Model: 1756-OF8IK (ControlLogix Series)
- Output Type: Isolated current (0-20mA/4-20mA)
- Voltage Range: 5-30V DC
- Resolution: 16-bit
- Response Time: 1ms scan time
- Load Capacity: Up to 1000 Ohms
- Power Use: 200mA @ 5.1VDC, 385mA @ 24VDC (max)
- Wire Size: 22-14 AWG (90°C rated)
Advanced Protection
- 🛡️ Withstands ±30V spikes
- 🛡️ Automatic short-circuit detection
- 🛡️ Open-circuit detection for all outputs
- 🛡️ Conformal coating for moisture protection
Your Assurance
- 🔒 12-month quality guarantee
- ✈ Fast worldwide delivery options
- 🛠 Easy installation with 1756-TBCH/TBS6H terminals
Technical FAQs
- Q: What’s the maximum load impedance supported?
A: 1000 Ohms for current output mode. - Q: Does this module support voltage outputs?
A: No, the 1756-OF8IK is current output only (0-20mA/4-20mA). - Q: What’s the power consumption at maximum load?
A: 10.2W with 1000 Ohm loads in current mode. - Q: Is special wiring required?
A: Use 22-14 AWG shielded copper wire (90°C rated). - Q: How fast is the signal processing?
A: 1ms module scan time for rapid response.
