Allen-Bradley 1756-L1 ControlLogix – Compact Automation Controller with RS232 Connectivity
Key Specifications
- Brand: Allen-Bradley
- Memory: 64KB user (expandable with memory modules)
- Ports: 1 RS232 communication port
- Power Use: 3.3W average (11.3 BTU/hour)
- Current Draw: 0.65A @5V DC / 0.02A @24V DC
- Temperature Range: 0°C to 60°C operating
- Shock Resistance: 30G operating / 50G non-operating
- Compatible Cables: 1756-CP3, 1747-CP3
Technical Questions
- Can multiple 1756-L1 controllers work together?
- Yes, install in same chassis
- What battery does it use?
- Only 1756-BA1 lithium battery
- Is Ethernet supported?
- Yes, via additional communication modules
- How to expand memory?
- Use 1756-M1/M2/M3 memory modules
- What programming languages work?
- Ladder, Function Block, SFC, Statement List
Package Includes
- 1756-L1 Controller Module
- Installation guide
- Mounting hardware
Support & Delivery
- 12-month product guarantee
- Fast shipping via major carriers
- Download technical specifications
