Allen-Bradley 1734-ACNR ControlNet Adapter Module
The 1734-ACNR module connects POINT I/O to ControlNet networks. Fast data transfer. Easy setup. Reliable performance for industrial automation.
Key Benefits
- Network Integration – Links I/O modules to ControlNet
- High Capacity – Supports up to 63 I/O modules
- Fast Communication – Quick data transfer speeds
- Easy Expansion – Grow your system easily
- Safe Operation – Reverse polarity protection
Technical Specifications
Brand: Allen-Bradley
Model: 1734-ACNR
Series: POINT I/O
Input Voltage: 24V DC
Power Requirement: 425 mA
Power Consumption: 8W
Inrush Current: 6A for 10 ms
POINTBus Current: 1000 mA
Power Dissipation: 2.8W at 28.8V
Max Power: 10.2W
Network Port: ControlNet
Connections: 5 rack-optimized + 25 direct
Module Support: Series C and newer
System Capacity
Works with up to 63 I/O modules. Needs 1734-EP24DC power supplies for expansion.
Installation Notes
Simple network setup. Local communication port available. Handles redundant media.
Warranty & Shipping
12-month product warranty. We ship worldwide via FedEx, UPS, DHL.
Get Complete Documentation
- Full installation guide
- Wiring diagrams
- Configuration steps
- Troubleshooting tips
Expert FAQ
How many connections does it support?
5 rack-optimized plus 25 direct connections maximum.
What I/O modules work with 1734-ACNR?
Only Series C and newer modules are compatible.
Can I expand the system?
Yes, supports up to 63 modules with extra power supplies.
What network features does it have?
Handles redundant media and has local network access port.
What is the maximum power?
10.2 watts maximum power consumption.
