Allen-Bradley PowerFlex 525 AC Drive | 25B-B5P0N104

Allen-Bradley 25B-B5P0N104 PowerFlex 525 Drive – Compact 1HP Motor Control

The 25B-B5P0N104 delivers reliable 1HP (0.75kW) motor control in a space-saving design. Perfect for small pumps, fans, and conveyors needing precise speed control.

Technical Details

• Model: 25B-B5P0N104 (PowerFlex 525 Series)
• Input: 170-264V AC, 3-Phase, 5.8A
• Output: 0-240V AC, 3-Phase, 5.0A
• Power: 0.75kW (1HP)
• Frequency: 0-500Hz adjustable
• Efficiency: 97.5% typical
• Protection: Overload, short-circuit, overvoltage
• Size: 72 x 152 x 172 mm

Connection Options

• 7 digital inputs (6 programmable)
• 2 analog inputs (0-10V/4-20mA)
• 2 relay outputs
• 1 analog output
• Ethernet/IP port

What You Get

• 25B-B5P0N104 drive unit
• Mounting hardware
• Quick start guide

Warranty & Shipping

12-month warranty. Ships via FedEx, UPS, or DHL with tracking.

Expert FAQs

• Q: Can this drive run on single-phase power?
  A: No, it requires 3-phase 240V input.
• Q: What’s the difference between V/Hz and Vector control?
  A: Vector control offers better torque at low speeds.
• Q: Does it include braking resistors?
  A: No, but has built-in braking control for adding resistors.
• Q: What’s the operating temperature range?
  A: -20°C to 50°C (-4°F to 122°F) without derating.
• Q: Can I add communication options later?
  A: Yes, optional adapters for DeviceNet/ProfiBus available.

Compare Similar Models

• 25B-D030N104 (3HP, 480V)
• 25B-D030N114 (3HP, 480V)
