Allen-Bradley PowerFlex 753 AC Drive 20F1AND248AA0NNNNN
The 20F1AND248AA0NNNNN is built for mid-to-high power motors.
It is simple to expand.
It fits many factory systems.
Basic Identification
- Manufacturer: Allen-Bradley
- Series: PowerFlex 753
- Model: 20F1AND248AA0NNNNN
- Frame Size: Frame 6
- Drive Type: Variable frequency drive
Power and Ratings
- Input Voltage: 480 VAC
- Phase: 3-phase
- Output Current: 248 Amps
- Motor Power: 200 HP normal duty
- Motor Power: 150 HP heavy duty
- DC Bus Level: 650 VDC
Thermal and Mechanical Design
- Cooling Method: Air cooled
- Enclosure: Open type
- Protection Rating: IP20 / IP00
- Approx. Weight: 200 lb
- Installation: Panel mount
Control and I/O
- Embedded I/O: Analog and digital
- Control Mode: Vector control
- Process Control: Built-in PID
- Local Display: No HIM installed
Electrical Features
- Input Stage: AC input with precharge
- DC Terminals: Not included
- EMI Filter: Integrated, jumper removable
- Braking: DB transistor supported
Overload and Protection
- Overload Capacity: 110% for 60 seconds
- Short Boost: 150% for 3 seconds
- Motor Protection: Electronic thermal model
- Fault Handling: Programmable trips
Expansion Capability
- Option Slots: 3 available
- Communication: Optional network cards
- Feedback: Encoder options supported
- Future Proof: Easy upgrades
Main Selling Points
- Strong torque at low speed
- Stable current output
- Built-in EMI filtering
- Flexible I/O design
- Trusted industrial platform
Warranty and Shipping
- Warranty: 12 months
- Shipping Options: FedEx, UPS, DHL
- Secure export packaging
Professional FAQ
- Is this drive suitable for pumps and fans?
- Yes. It works well with variable torque loads.
- How do I choose ND or HD rating?
- Check load type and duty cycle.
- Can I add fieldbus later?
- Yes. Use one expansion slot.
- Is air cooling enough?
- Yes, with correct cabinet airflow.
- Does it support future expansion?
- Yes. Hardware and software options are flexible.
