Product Overview – Schneider Electric ATV61HU40N4
- Brand: Schneider Electric
- Model: ATV61HU40N4
- Series: Altivar 61
- Type: Variable Speed Drive
- Rated Power: 4 kW / 5 HP
- Supply Voltage: 380–480 V AC, 3-phase
- Supply Frequency: 50/60 Hz
- Integrated EMC filter improves noise immunity.
- Heat sink design ensures stable cooling.
- Supports precise motor speed and torque control.
- Suitable for HVAC, pumps, and conveyors.
Technical Specifications
- Brand: Schneider Electric
- Model: ATV61HU40N4
- Product Line: Altivar 61
- Power Rating: 4 kW / 5 HP
- Line Current: 5.4 A
- Apparent Power: 5.5 kVA
- Maximum Transient Current: 7.5 A for 60 seconds
- Nominal Switching Frequency: 12 kHz
- Switching Range: 1–16 kHz adjustable
- Protection Class: IP20
- Assembly Style: With heat sink
- Weight: 11.34 kg
- Operating Temperature: 0°C to 50°C typical
- EMC Protection: Integrated suppression filter
- Environmental Use: Indoor industrial cabinet
- Control Accuracy: Stable torque response
- Resolution: Fine digital speed adjustment
- Linearity: Consistent output across speed range
Configuration Breakdown
- ATV
- Altivar drive platform
- 61
- Series for fluid and HVAC control
- H
- High performance structure
- U40
- 4.0 kW power class
- N4
- 380–480 V 3-phase rating
Core Functional Advantages
- Accurate speed regulation
- Energy saving operation under variable load.
- Overload capacity for short-term peaks.
- Adjustable switching frequency reduces motor noise.
- Built-in diagnostics for fast troubleshooting.
Installation Guidelines
- Mount vertically inside a ventilated cabinet.
- Keep airflow clearance around heat sink.
- Use proper grounding for EMC performance.
- Select cable size based on rated current.
- Avoid high humidity environments.
Commissioning & Maintenance
- Set motor parameters before first startup.
- Adjust acceleration and deceleration time carefully.
- Monitor fault codes via display panel.
- Clean cooling surfaces during maintenance.
- Inspect terminals regularly.
Compatibility
- Works with standard 3-phase induction motors.
- Compatible with 50 Hz and 60 Hz systems.
- Suitable for HVAC automation networks.
- Integrates into industrial control cabinets.
Typical Applications
- Water pumps
- Cooling fans
- Air handling units
- Industrial conveyors
- Process machinery
Packaging & Warranty
- 1 × ATV61HU40N4 Drive
- Product documentation
- Factory sealed package
- 12-Month Warranty
- Express Shipping: FedEx / UPS / DHL
FAQ
- Can this unit drive a 5 HP motor?
- Yes. It matches 4 kW or 5 HP motors.
- Does it include EMC protection?
- Yes. It has an integrated EMC filter.
- How to select the correct drive?
- Check motor rated current first.
- Consider overload and ambient temperature.
- Why does overcurrent alarm appear?
- Possible sudden load change or wrong parameter setup.
- Verify wiring and acceleration settings.
- Is it suitable for outdoor use?
- No. IP20 requires indoor installation.
