Bently Nevada 11 mm Proximity Probe 330702-00-10-90-12-00

Bently Nevada 3300 XL 11mm Proximity Probe – 9m Cable Version

Industrial-grade vibration sensor with 9-meter armored cable. Perfect for hard-to-reach machinery monitoring. Made in the USA.

Key Features

• Model: 3300 XL 11mm (P/N: 330702-00-10-90-12-00)
• Long Reach: 9m (29.5ft) FluidLoc cable
• Extreme Durability: 304 stainless steel case + PPS tip
• Wide Temp Range: -51°C to +177°C
• Easy Connection: Mini ClickLoc connector

Complete Suffix Breakdown

• 330702 = Base model (11mm, 1/2-20 UNF, armored)
• 00 = 0.0″ unthreaded length
• 10 = 1.0″ case length
• 90 = 9.0m total cable
• 12 = ClickLoc/FluidLoc
• 00 = No agency approvals

Technical Specifications

• Cable Resistance: 8.5Ω ±1.1
• Thread Size: 1/2-20 UNF or M16x1.5
• Max Torque: 45.2 N•m (do not exceed)
• Bend Radius: >25.4mm (1.0″)
• Seal Material: Viton O-ring
• Cable Type: 75Ω triaxial FEP
• Weight: 0.17kg

5 Professional FAQs

• Q: Can I cut the 9m cable shorter?
  A: No – cutting voids warranty
• Q: Is the probe waterproof?
  A: FluidLoc cable resists fluids but isn’t fully waterproof
• Q: What’s the minimum temp for installation?
  A: -34°C to avoid seal damage
• Q: Does it work with 5m systems?
  A: No – only for 9m Proximitors
• Q: How to prevent cable damage?
  A: Maintain >1″ bend radius

Warranty & Shipping

• 12-month warranty on materials/workmanship
• Global shipping via FedEx/UPS/DHL
• Typical delivery: 3-7 business days
