Bently Nevada 11 mm Proximity Probe 330702-00-24-90-11-00

Bently Nevada 3300 XL 11mm Proximity Probe – 9m Cable (Model: 330702-00-24-90-11-00)

Key Features

• 9-meter armored cable for flexible installation.
• Works with 3300 XL Proximitor sensors.
• Stainless steel case (AISI 304) and PPS tip for durability.
• Wide temperature range: -51°C to +177°C.
• ClickLoc connector with FluidLoc cable (dust/oil resistant).

Technical Specifications

• Model: 330702-00-24-90-11-00
• Thread: 1/2-20 UNF
• Cable Length: 9.0 meters (29.5 ft)
• Resistance: 8.5 ± 1.1 ohms (center to outer conductor)
• Max Torque: 15.2 N•m (133 in•lb)
• Bend Radius: 25.4 mm (1.0 in)
• Weight: 0.17 kg

Model Suffix Explained

• 330702 → 3300 XL 11mm Probe
• 00 → No agency approval
• 24 → 2.4-inch case length
• 90 → 9.0-meter cable
• 11 → ClickLoc connector + protector
• 00 → No extra options

Installation Notes

• Max thread engagement: 0.750 in.
• Do not expose to temps below -34°C (30°F).
• Connector torque: Finger tight (max 0.565 N•m).

Shipping & Warranty

• Fast shipping via FedEx, UPS, or DHL.
• 12-month warranty from delivery.

FAQ

• Q: Can this probe measure shaft vibration?
  A: Yes, it’s designed for vibration and position monitoring.
• Q: Is the cable oil-resistant?
  A: Yes, the FluidLoc cable resists oil and dust.
• Q: What’s the max pressure for the seal?
  A: Contact Bently Nevada for custom pressure testing.
• Q: Can I cut the cable to a shorter length?
  A: No—cutting voids warranty. Use the correct length.
• Q: Does it work with non-Bently Nevada systems?
  A: Compatibility is limited to 3300 XL Proximitors.
