Bently Nevada 3300 XL 11 mm Proximity Probe 330708-00-24-90-01-00

Bently Nevada 3300 XL 11mm Proximity Probe: Precision Vibration Monitoring

Description

Industrial vibration sensor for machinery health monitoring. Features PPS tip and 304 SST case. Withstands extreme temperatures (-51°C to +177°C). Ideal for turbines, pumps, and compressors.

• Download full specs: Installation Manual (PDF)

Technical Data

• Brand: Bently Nevada
• Model: 3300 XL 11mm Proximity Probe
• Full Suffix: 330708-00-24-90-01-00

Suffix Breakdown

• 330708: 11mm Probe, 5/8-18 UNF thread
• 00: 0″ unthreaded length
• 24: 2.4″ case length
• 90: 9.0m cable (29.5 ft)
• 01: Miniature coaxial ClickLoc connector
• 00: No agency approval

Key Specifications

• Temperature Range: -51°C to +177°C
• Probe Resistance: 8.5Ω ±1.1Ω (9m cable)
• Cable: 75Ω triaxial FEP
• Min Bend Radius: 25.4mm (1.0in)
• Thread Torque: Max 45.2N·m / Rec 15.2N·m
• Pressure Seal: Viton O-ring (test available)

Installation Guide

• Max thread engagement: 0.938″ (5/8-18 UNF)
• Connector torque: 0.565N·m max (finger-tight recommended)
• Avoid temperatures below -34°C to prevent seal damage

Maintenance & Compatibility

• Works with Bently Nevada 3300 monitoring systems
• No calibration needed – plug-and-play setup

Certifications & Packaging

• 12-month warranty
• Shipping: FedEx/UPS/DHL (0.17kg)
• Box includes: Probe, connector protector

Applications & Diagnostics

• Detects shaft vibration in:
  • Power generation turbines
  • Oil & gas compressors
  • Industrial pumps
• Diagnoses: Bearing wear, imbalance, misalignment

FAQ

• Q: Pressure rating?
  A: Contact us for custom pressure tests
• Q: Cable length options?
  A: 1m, 5m, or 9m (as ordered)
• Q: Suitable for explosive environments?
  A: No agency approvals (suffix 00)
